实验要求
压缩软件是利用特定算法来压缩数据的工具,压缩后生成的文件称为压缩包(archive)。如果想使用其中的数据,就得用压缩软件对数据进行解压。利用压缩软件对文件中重复的数据进行压缩,可以减小文件中的字节总数,使文件能够通过互联网连接实现更快传输,此外还可以减少文件的磁盘占用空间。常用的压缩软件有 rar、zip 等。
压缩可以分为无损压缩与有损压缩两种。无损压缩后的文件,经过解压能够完全恢复原始数据;有损压缩的文件则无法完全恢复。rar、zip 等格式都是无损压缩格式。音乐文件格式 mp3、图片文件格式 jpg 都是有损压缩格式。
计算机文件是由一个个字节组成的,1 个字节有 0~255 共 256 种可能的值,每个字节的编码长度都是 8 位。由于文件中的字节总是会重复出现,可以对不同的字节设计长度不等的编码,让出现次数较多的字节,采用尽可能短的编码,那么文件编码的总长便可减
少。
统计文件中 256 种不同的字节重复的次数,以每种字节重复的次数作为权值(weight),构造一棵有 256 个叶子节点的二叉树。若带权路径长度达到最小,称这样的二叉树为最优二叉树,即 Huffman 树(Huffman tree)。
Huffman 树从根到每个叶子都有一条路径。对路径上的各分支,约定指向左子树根的分支编码为“0”,指向右子树根的分支编码为“1”。从根到每个叶子相应路径上的“0”和“1”组成的序列,就是这个叶子节点的编码,称为 Huffman 编码。
功能要求:使用 Huffman 压缩算法,对一幅 BMP 格式的图片文件进行压缩。图片文件名为“Pic.bmp”,内容如下图所示。压缩后保存为“Pic.bmp.huf”文件。
效果展示
哈夫曼图片压缩
源码
Compress.cpp
#define _CRT_SECURE_NO_WARNINGS
#include <iostream>
#include <stdlib.h>
#include "Compress.h"
#include"Huffman.h"
#include"global.h"
using namespace std;;
const int SIZE = 256;
//实现文件压缩
int Compress(const char* pFilename)
{
cout << endl;
//打开并扫描文件
cout << "正在读取文件……" << endl << endl;
int weight[256] = {
0 };
FILE* in = fopen(pFilename, "rb");
int tempch;
//获取权重
while ((tempch = getc(in)) != EOF)
weight[tempch]++;
int temp;
cout << "输入数字“1”显示256种字节出现次数,输入其它数字则不显示!" << endl;
cout << "请输入您的选择:";
cin >> temp;
cout << endl;
if (temp == 1) {
//测试,显示256种字节出现的次数
showWeight(weight);
cout << endl;
}
cout << "文件读取完毕!\n" << endl;
//关闭文件
fclose(in);
//将编码生成Huffman树
//Huffman树共有n个叶子节点
int n = 256;
//那么就有2n+1个节点
int m = 2 * n - 1;
//定义Huffman树
HuffmanTree pHT = new HTNode[m + 1];
CreateHuffmanTree(pHT, weight, n);
int temp1;
cout << "输入数字“1”显示Huffman 树每个节点的信息,输入其它数字则不显示!" << endl;
cout << "请输入您的选择:";
cin >> temp1;
cout << endl;
if (temp1 == 1) {
//测试,输出 Huffman 树每个节点的信息
TestHufTree(pHT);
cout << endl;
}
//生成Huffman编码
char** pHC = new char* [n + 1]; //编码
for (int i = 1; i <= n; i++)
pHT[i].weight = weight[i - 1];
HuffmanCoding(pHC, pHT);
int temp2;
cout << "输入数字“1”显示字节的Huffman编码信息,输入其它数字则不显示!" << endl;
cout << "请输入您的选择:";
cin >> temp2;
cout << endl;
if (temp2 == 1) {
//测试,显示字节的Huffman编码信息
cout << "\n哈夫曼树的编码信息为:" << endl;
cout << "Byte\tHuffmanCode" << endl;
TestHufCode(511, pHT, pHC);
cout << endl;
}
//计算编码缓冲区大小
int nSize = 0;
for (int i = 0; i < 256; i++)
nSize += weight[i] * strlen(pHC[i + 1]);
nSize = (nSize % 8) ? nSize / 8 + 1 : nSize / 8;
//对编码文件进行压缩
char* pBuffer = NULL;
pBuffer = new char[nSize];
memset(pBuffer, 0, (nSize) * sizeof(char));
Encode(pFilename, pHC, pBuffer, nSize);
if (!pBuffer) {
return ERROR;
}
HEAD sHead;
InitHead(pFilename, sHead);
cout << "原文件大小:" << sHead.length << "字节" << endl;
int afterlen = WriteFile(pFilename, sHead, pBuffer, nSize);
cout << "压缩后文件大小:" << afterlen << "字节" << endl;
cout << "压缩比率:" << (double)afterlen * 100 / sHead.length << "%" << endl;
delete pHT;
delete[] pHC;
delete pBuffer;
return OK;
}
//扫描文件和初始化头文件的信息
int InitHead(const char* pFilname, HEAD& sHead)
{
//文件类型
strcpy(sHead.type, "HUF");
//源文件长度
sHead.length = 0;
for (int i = 0; i < SIZE; i++)
//权值
sHead.weight[i] = 0;
//以二进制流形式打开文件
FILE* in = fopen(pFilname, "rb");
//扫描文件,获得权重
int ch;
while ((ch = fgetc(in)) != EOF) {
sHead.weight[ch]++;
sHead.length++;
}
//关闭文件
fclose(in);
in = NULL;
return OK;
}
//实现压缩编码
int Encode(const char* pFilname, const HuffmanCode pHC, char* pBuffer, const int nSize)
{
//打开文件
FILE* in = fopen(pFilname, "rb");
//开辟缓冲区ni
pBuffer = (char*)malloc(nSize * sizeof(char));
if (!pBuffer)
cout << "开辟缓冲区失败!" << endl;
//工作区
char cd[SIZE] = {
0 };
//缓冲区指针
int pos = 0;
int ch;
//扫描文件
while ((ch = fgetc(in)) != EOF) {
strcat(cd, pHC[ch + 1]);
//压缩编码
while (strlen(cd) >= 8) {
pBuffer[pos++] = Str2byte(cd);
for (int i = 0; i < SIZE - 8; i++) {
cd[i] = cd[i + 8];
}
}
}
if (strlen(cd) > 0) {
pBuffer[pos++] = Str2byte(cd);
}
fclose(in);
return OK;
}
//生成压缩文件
int WriteFile(const char* pFilename, const HEAD sHead, const char* pBuffer, const int nSize)
{
//生成文件名
char filename[256] = {
0 };
strcpy(filename, pFilename);
strcat(filename, ".huf");
//以二进制流形式打开文件
FILE* out = fopen(filename, "wb");
//写文件
fwrite(&sHead, sizeof(HEAD), 1, out);
//写压缩后的编码
fwrite(pBuffer, sizeof(char), nSize, out);
//关闭文件,释放文件指针
fclose(out);
out = NULL;
cout << "生成压缩文件:" << filename << endl;
int len = sizeof(HEAD) + strlen(pFilename) + 1 + nSize;
return len;
}
//将字符串转换成字节
char Str2byte(const char* pBinStr)
{
char b = 0x00;
for (int i = 0; i < 8; i++) {
//左移一位
b = b << 1;
if (pBinStr[i] == '1') {
b = b | 0x01;
}
}
return b;
}
Compress.h
#pragma once
#include"Huffman.h" //Encode函数声明会用到HuffmanCode
//文件头
struct HEAD
{
char type[4];
int length;
int weight[256];
};
//实现文件压缩
int Compress(const char* pFilename);
//读取源文件和初始化头文件的信息
int InitHead(const char* pFilname, HEAD& sHead);
//利用Huffman编码 实现压缩编码
int Encode(const char* pFilname, const HuffmanCode pHC, char* pBuffer, const int nSize);
//将二进制字符串转换成字节
char Str2byte(const char* pBinStr);
//生成压缩文件
int WriteFile(const char* pFilename, const HEAD sHead, const char* pBuffer, const int nSize);
global.h
#pragma once
#define OK 1
#define ERROR 0
Huffman.cpp
#define _CRT_SECURE_NO_WARNINGS
#include<iostream>
#include<malloc.h>
#include"Huffman.h"
#include"global.h"
using namespace std;
// 显示 256 种字节的出现的次数
void showWeight(int weight[])
{
cout << "原文件每个字符的权值为:" << endl;
cout << "Byte\t" << "Weight\t" << endl;
for (int i = 0; i < 256; i++)
printf("0x%02X\t%d\n", i, weight[i]);
}
//生成Huffman树
int CreateHuffmanTree(HuffmanTree pHT, int weight[], int n)
{
int s1, s2, i;
int m = 2 * n - 1;
//初始化
for (i = 1; i <= n; i++) {
pHT[i].weight = weight[i - 1];
pHT[i].lchild = 0;
pHT[i].rchild = 0;
pHT[i].parent = 0;
}
for (i = n + 1; i <= m; i++) {
pHT[i].parent = 0;
pHT[i].lchild = 0;
pHT[i].rchild = 0;
pHT[i].weight = 0;
}
for (i = n + 1; i <= m; i++) {
//从pHT[1...i-1]中选择parent为0且weight最小的两个结点,其序号分别为s1和s2
Select(pHT, i - 1, s1, s2);
pHT[s1].parent = i;
pHT[s2].parent = i; //修改s1和s2结点的父指针parent
pHT[i].lchild = s1;
pHT[i].rchild = s2; //修改i结点的左右孩子指针
pHT[i].weight = pHT[s1].weight + pHT[s2].weight; //修改权值
}
return OK;
}
//查找Huffman树节点数组中权值最小的节点
void Select(HuffmanTree& pHT, int i, int& s1, int& s2)
{
int minValue = 0x7FFFFFFF;
//找到最小的一个权值
for (int j = 1; j <= i; j++) {
if (pHT[j].parent == 0 && pHT[j].weight < minValue) {
minValue = pHT[j].weight;
s1 = j;
}
}
minValue = 0x7FFFFFFF;
//找到倒数第二小的权值
for (int j = 1; j <= i; j++) {
if (j != s1 && pHT[j].parent == 0 && pHT[j].weight < minValue) {
minValue = pHT[j].weight;
s2 = j;
}
}
}
//生成Huffman编码
int HuffmanCoding(HuffmanCode& pHC, HuffmanTree& pHT)
{
//无栈非递归遍历Huffman树,求Huffman编码
//记录访问路径
char cd[256] = {
'\0' };
//记录当前路径长度
int cdlen = 0;
//遍历Huffman树时用做节点的状态标志
for (int i = 1; i < 512; i++)
pHT[i].weight = 0;
int p = 511;
while (p != 0) {
//向左
if (pHT[p].weight == 0) {
pHT[p].weight = 1;
if (pHT[p].lchild != 0) {
p = pHT[p].lchild;
cd[cdlen++] = '0';
}
//登记叶子节点的字符的编码
else if (pHT[p].rchild == 0) {
pHC[p] = (char*)malloc((cdlen + 1) * sizeof(char));
cd[cdlen] = '\0';
strcpy(pHC[p], cd);//复制编码
}
}
//向右
else if (pHT[p].weight == 1) {
pHT[p].weight = 2;
//右孩子为叶子节点
if (pHT[p].rchild != 0) {
p = pHT[p].rchild;
cd[cdlen++] = '1';
}
}
//退回父节点,编码长度减一
else {
pHT[p].weight = 0;
p = pHT[p].parent;
cdlen--;
}
}
return OK;
}
//测试函数,输出哈夫曼树的每个节点信息
int TestHufTree(HuffmanTree pHT) {
cout << "哈夫曼树的每个节点信息为:" << endl;
cout << "Byte\t\tWeight\tParent\tLchild\tRchild\n";
for (int i = 1; i < 512; i++) {
//判断语句为了对齐格式
if (i <= 99)
cout << "pHT[" << i << "]\t\t" << pHT[i].weight << "\t" << pHT[i].parent << "\t" << pHT[i].lchild << "\t" << pHT[i].rchild << endl;
else
cout << "pHT[" << i << "]\t" << pHT[i].weight << "\t" << pHT[i].parent << "\t" << pHT[i].lchild << "\t" << pHT[i].rchild << endl;
}
return OK;
}
//测试函数,采用先序遍历的方法,输出 Huffman 树每个节点的信息
void TestHufCode(int root, HuffmanTree& pHT, HuffmanCode& pHC)
{
if (root <= 1) return;
if (pHT[root].lchild == 0 && pHT[root].rchild == 0)
printf("0x%02X\t%s\n", root - 1, pHC[root - 1]);
if (pHT[root].lchild)//访问左孩子
TestHufCode(pHT[root].lchild, pHT, pHC);
if (pHT[root].rchild)//访问右孩子
TestHufCode(pHT[root].rchild, pHT, pHC);
}
Huffman.h
#pragma once
//Huffman树节点
typedef struct
{
int weight; //权值
int parent; //父节点
int lchild; //左孩子
int rchild; //右孩子
}HTNode, * HuffmanTree;
//Huffman编码
typedef char** HuffmanCode;
// 显示 256 种字节的出现的次数
void showWeight(int weight[]);
//生成Huffman树
int CreateHuffmanTree(HuffmanTree pHT, int weight[], int n);
//生成Huffman编码
int HuffmanCoding(HuffmanCode& pHC, HuffmanTree& pHT);
//查找 Huffman 树结点数组中权值最小的节点
void Select(HuffmanTree& HT, int i, int& s1, int& s2);
//测试函数,输出哈夫曼树的每个节点信息
int TestHufTree(HuffmanTree pHT);
//测试函数,采用先序遍历的方法,输出 Huffman 树每个节点的信息
void TestHufCode(int root, HuffmanTree& pHT, HuffmanCode& pHC);
main.cpp
#include<iostream>
#include"Compress.h"
using namespace std;
int main(void) {
cout << "========== Huffman 文件压缩 ==========" << endl;
cout << "请输入文件名:";
char filename[256];
cin >> filename;
if (Compress(filename) == 1)
cout << "\n文件压缩成功!" << endl;
else
cout << "\n文件压缩失败!" << endl;
return 0;
}
