前言
作用Android开发者，相信大家都知道Glide这款优秀的Android图片加载库。它支持拉取、解码、展示，视频快照、图片和GIF动画。提供了易用的API，高性能、可扩展的图片解码管道（
decode pipeline），以及自动的资源池技术。Glide 使用简明的流式（链式）语法API，这是一个非常棒的设计，因为它允许你在大部分情况下一行代码搞定需求，因此搞懂这条链式调用的代码都做了什么准备工作，Glide图片加载的大概框架也就明白了许多。
Glide.with(context)
.load(url)
.into(imageView);配置要求
Glide v4最低支持Android Ice Cream Sandwich (API level 14).
优势概述
Glide比较吸引人的主要还是与Activity生命周期进行绑定、加载gif图片、可以配置相应的网络请求框架。
一、With(）
概述：With() 通过RequestManagerRetriever的单例，静态get方法拿到其对象实例，然后通过成员函数get方法，通过getApplicationManager(Context)方法最终拿到RequestManager实例。
//1 Context
public static RequestManager with(Context context) {
RequestManagerRetriever retriever = RequestManagerRetriever.get();
/**
* retriever n. （训练成能寻回猎物的）寻回犬；取回的人，挽救者
*/
return retriever.get(context);
}
//2 Activity
public static RequestManager with(Activity activity) {
RequestManagerRetriever retriever = RequestManagerRetriever.get();
return retriever.get(activity);
}
//3 FragmentActivity
public static RequestManager with(FragmentActivity activity) {
RequestManagerRetriever retriever = RequestManagerRetriever.get();
return retriever.get(activity);
}
//4 android.app.Fragment
@TargetApi(Build.VERSION_CODES.HONEYCOMB)
public static RequestManager with(android.app.Fragment fragment) {
RequestManagerRetriever retriever = RequestManagerRetriever.get();
return retriever.get(fragment);
}
//5 Fragment
public static RequestManager with(Fragment fragment) {
RequestManagerRetriever retriever = RequestManagerRetriever.get();
return retriever.get(fragment);
}上面共有五种with方法重载。都是调用RequestManagerRetriever类的静态get方法获取到实例对象，属于是一个饿汉式单例模式。然后，再将参数传入retriever对象的get方法中，拿到RequestManager对象。源码如下：
RequestManagerRetriever.class
public class RequestManagerRetriever implements Handler.Callback {
//...
final Map<FragmentManager, SupportRequestManagerFragment> pendingSupportRequestManagerFragments =
new HashMap<FragmentManager, SupportRequestManagerFragment>();
//...
public static RequestManagerRetriever get() {
return INSTANCE;
}
RequestManagerRetriever() {
handler = new Handler(Looper.getMainLooper(), this /* Callback */);
}
private RequestManager getApplicationManager(Context context) {
if (applicationManager == null) {
synchronized (this) {
if (applicationManager == null) {
applicationManager = new RequestManager(context.getApplicationContext(),
new ApplicationLifecycle(), new EmptyRequestManagerTreeNode());
}
}
}
return applicationManager;
}
public RequestManager get(Context context) {
if (context == null) {
//..
} else if (Util.isOnMainThread() && !(context instanceof Application)) {
if (context instanceof FragmentActivity) {
return get((FragmentActivity) context);
} else if (context instanceof Activity) {
return get((Activity) context);
} else if (context instanceof ContextWrapper) {
return get(((ContextWrapper) context).getBaseContext());
}
}
return getApplicationManager(context);
}
public RequestManager get(FragmentActivity activity) {
if (Util.isOnBackgroundThread()) {
return get(activity.getApplicationContext());
} else {
assertNotDestroyed(activity);
FragmentManager fm = activity.getSupportFragmentManager();
return supportFragmentGet(activity, fm);
}
}
public RequestManager get(Fragment fragment) {
if (fragment.getActivity() == null) {
//..
}
if (Util.isOnBackgroundThread()) {
return get(fragment.getActivity().getApplicationContext());
} else {
FragmentManager fm = fragment.getChildFragmentManager();
return supportFragmentGet(fragment.getActivity(), fm);
}
}
@TargetApi(Build.VERSION_CODES.HONEYCOMB)
public RequestManager get(Activity activity) {
if (Util.isOnBackgroundThread() || Build.VERSION.SDK_INT < Build.VERSION_CODES.HONEYCOMB) {
return get(activity.getApplicationContext());
} else {
assertNotDestroyed(activity);
android.app.FragmentManager fm = activity.getFragmentManager();
return fragmentGet(activity, fm);
}
}
@TargetApi(Build.VERSION_CODES.JELLY_BEAN_MR1)
private static void assertNotDestroyed(Activity activity) {
if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.JELLY_BEAN_MR1 && activity.isDestroyed()) { //..
}
}
@TargetApi(Build.VERSION_CODES.JELLY_BEAN_MR1)
public RequestManager get(android.app.Fragment fragment) {
if (fragment.getActivity() == null) { //..
}
if (Util.isOnBackgroundThread() || Build.VERSION.SDK_INT < Build.VERSION_CODES.JELLY_BEAN_MR1) {
return get(fragment.getActivity().getApplicationContext());
} else {
android.app.FragmentManager fm = fragment.getChildFragmentManager();
return fragmentGet(fragment.getActivity(), fm);
}
}
@TargetApi(Build.VERSION_CODES.JELLY_BEAN_MR1)
RequestManagerFragment getRequestManagerFragment(final android.app.FragmentManager fm) {
RequestManagerFragment current = (RequestManagerFragment) fm.findFragmentByTag(FRAGMENT_TAG);
if (current == null) {
current = pendingRequestManagerFragments.get(fm);
if (current == null) {
current = new RequestManagerFragment();
pendingRequestManagerFragments.put(fm, current);
fm.beginTransaction().add(current, FRAGMENT_TAG).commitAllowingStateLoss();
handler.obtainMessage(ID_REMOVE_FRAGMENT_MANAGER, fm).sendToTarget();
}
}
return current;
}
@TargetApi(Build.VERSION_CODES.HONEYCOMB)
RequestManager fragmentGet(Context context, android.app.FragmentManager fm) {
RequestManagerFragment current = getRequestManagerFragment(fm);
RequestManager requestManager = current.getRequestManager();
if (requestManager == null) {
requestManager = new RequestManager(context, current.getLifecycle(), current.getRequestManagerTreeNode());
current.setRequestManager(requestManager);
}
return requestManager;
}
SupportRequestManagerFragment getSupportRequestManagerFragment(final FragmentManager fm) {
SupportRequestManagerFragment current = (SupportRequestManagerFragment) fm.findFragmentByTag(
FRAGMENT_TAG);
if (current == null) {
current = pendingSupportRequestManagerFragments.get(fm);
if (current == null) {
current = new SupportRequestManagerFragment();
pendingSupportRequestManagerFragments.put(fm, current);
fm.beginTransaction().add(current, FRAGMENT_TAG).commitAllowingStateLoss();
handler.obtainMessage(ID_REMOVE_SUPPORT_FRAGMENT_MANAGER, fm).sendToTarget();
}
}
return current;
}
RequestManager supportFragmentGet(Context context, FragmentManager fm) {
SupportRequestManagerFragment current = getSupportRequestManagerFragment(fm);
RequestManager requestManager = current.getRequestManager();
if (requestManager == null) {
requestManager = new RequestManager(context, current.getLifecycle(), current.getRequestManagerTreeNode());
current.setRequestManager(requestManager);
}
return requestManager;
}
@Override
public boolean handleMessage(Message message) {
boolean handled = true;
Object removed = null;
Object key = null;
switch (message.what) {
case ID_REMOVE_FRAGMENT_MANAGER:
android.app.FragmentManager fm = (android.app.FragmentManager) message.obj;
key = fm;
removed = pendingRequestManagerFragments.remove(fm);
break;
case ID_REMOVE_SUPPORT_FRAGMENT_MANAGER:
FragmentManager supportFm = (FragmentManager) message.obj;
key = supportFm;
removed = pendingSupportRequestManagerFragments.remove(supportFm);
break;
default:
handled = false;
}
if (handled && removed == null && Log.isLoggable(TAG, Log.WARN)) {
//..
}
return handled;
}
}上面的静态get()挺多，其实只分为两种，即application类型与非application类型的参数。如果是application类型参数，会调用getApplicationManager(Context)，最后返回一个RequestManager对象实例；如果是非application类型参数，最后都会向当前的Activity添加一个隐藏的Fragmen。
Glide需要拿到加载的生命周期，当我们在Activity加载一张图片，图片还没有加载，Activity就被销毁了，那图片就不用加载。把Glide放到Fragment中，当Activity销毁，Fragment是可以监听到的，这样也可以实现需求。
二、load()
概述：load()方法通过fromString()调用loadGeneric()，返回asBitmap()相关的DrawableTypeRequest对象，调用DrawableRequestBuilder父类中load方法，给父类成员变量赋值后，在RequestManager类中将DrawableRequestBuilder父类对象强转成子类DrawableTypeRequest。load方法最终拿到了DrawableTypeRequest对象。
我们都知道Glide可以加载本地图片、res目录下图片、网络图片等等。所以load()方法也是有很多方法重载的。这里只看网络加载图片URL字符串的load()方法，查看源码如下。
RequestManager.class
public class RequestManager extends DrawableRequestBuilder implements LifecycleListener {
//...
public DrawableTypeRequest<String> load(String string) {
return (DrawableTypeRequest<String>) fromString().load(string);
}
public DrawableTypeRequest<String> fromString() {
return loadGeneric(String.class);
}
private <T> DrawableTypeRequest<T> loadGeneric(Class<T> modelClass) {
//streamModelLoader
ModelLoader<T, InputStream> streamModelLoader = Glide.buildStreamModelLoader(modelClass, context);
//fileDescriptorModelLoader
ModelLoader<T, ParcelFileDescriptor> fileDescriptorModelLoader =
Glide.buildFileDescriptorModelLoader(modelClass, context);
if (modelClass != null && streamModelLoader == null && fileDescriptorModelLoader == null) {
throw new IllegalArgumentException("Unknown type " + modelClass + ". You must provide a Model of a type for"
+ " which there is a registered ModelLoader, if you are using a custom model, you must first call"
+ " Glide#register with a ModelLoaderFactory for your custom model class");
}
// DrawableTypeRequest()
return optionsApplier.apply(
new DrawableTypeRequest<T>(modelClass, streamModelLoader, fileDescriptorModelLoader, context,
glide, requestTracker, lifecycle, optionsApplier));
}
}可见，load()最终调用了loadGeneric()。其中，Glide.buildStreamModelLoader、buildFileDescriptorModelLoader静态方法来拿到相应的ModelLoader对象。ModelLoader对象用于加载图片，传入不同的参数能拿到对应的ModelLoader对象。最终传入到 DrawableTypeRequest构造方法中，如下。
public class DrawableTypeRequest<ModelType> extends DrawableRequestBuilder<ModelType> implements DownloadOptions {
private final ModelLoader<ModelType, InputStream> streamModelLoader;
private final ModelLoader<ModelType, ParcelFileDescriptor> fileDescriptorModelLoader;
private final RequestManager.OptionsApplier optionsApplier;
private static <A, Z, R> FixedLoadProvider<A, ImageVideoWrapper, Z, R> buildProvider(Glide glide,
ModelLoader<A, InputStream> streamModelLoader,
ModelLoader<A, ParcelFileDescriptor> fileDescriptorModelLoader, Class<Z> resourceClass,
Class<R> transcodedClass,
ResourceTranscoder<Z, R> transcoder) {
if (streamModelLoader == null && fileDescriptorModelLoader == null) {
return null;
}
if (transcoder == null) {
transcoder = glide.buildTranscoder(resourceClass, transcodedClass);
}
DataLoadProvider<ImageVideoWrapper, Z> dataLoadProvider = glide.buildDataProvider(ImageVideoWrapper.class,
resourceClass);
ImageVideoModelLoader<A> modelLoader = new ImageVideoModelLoader<A>(streamModelLoader,
fileDescriptorModelLoader);
return new FixedLoadProvider<A, ImageVideoWrapper, Z, R>(modelLoader, transcoder, dataLoadProvider);
}
DrawableTypeRequest(Class<ModelType> modelClass, ModelLoader<ModelType, InputStream> streamModelLoader,
ModelLoader<ModelType, ParcelFileDescriptor> fileDescriptorModelLoader, Context context, Glide glide,
RequestTracker requestTracker, Lifecycle lifecycle, RequestManager.OptionsApplier optionsApplier) {
super(context, modelClass,
buildProvider(glide, streamModelLoader, fileDescriptorModelLoader, GifBitmapWrapper.class,
GlideDrawable.class, null),
glide, requestTracker, lifecycle);
this.streamModelLoader = streamModelLoader;
this.fileDescriptorModelLoader = fileDescriptorModelLoader;
this.optionsApplier = optionsApplier;
}
public BitmapTypeRequest<ModelType> asBitmap() {
return optionsApplier.apply(new BitmapTypeRequest<ModelType>(this, streamModelLoader,
fileDescriptorModelLoader, optionsApplier));
}
public GifTypeRequest<ModelType> asGif() {
return optionsApplier.apply(new GifTypeRequest<ModelType>(this, streamModelLoader, optionsApplier));
}
}
这个类中重点在于asGif()、asBitmap(）这两个方法，加载静态图片和动态图片的不同方式，分别创建了BitmapTypeRequest和GIFTypeRequest对象，如果不指定的话默认是创建静态图片的对象BitmapTypeRequest。
三、into()
概述：①初始化各种参数，做好准备工作（网络请求、基于MVP的各种接口回调），②使用最原始的HTTPConnect网络连接，读取文件流，③根据文件判断是GIF动图还是Bitmap静态图片，④通过相关复杂逻辑将下载的图片资源取出来，赋值给ImageView控件。
Into()是RequestManager的父类是DrawableRequestBuilder中的方法，源码如下。
public class DrawableRequestBuilder<ModelType>
extends GenericRequestBuilder<ModelType, ImageVideoWrapper, GifBitmapWrapper, GlideDrawable>
implements BitmapOptions, DrawableOptions {
DrawableRequestBuilder(Context context, Class<ModelType> modelClass,
LoadProvider<ModelType, ImageVideoWrapper, GifBitmapWrapper, GlideDrawable> loadProvider, Glide glide,
RequestTracker requestTracker, Lifecycle lifecycle) {
super(context, modelClass, loadProvider, GlideDrawable.class, glide, requestTracker, lifecycle);
crossFade();
}
public DrawableRequestBuilder<ModelType> thumbnail(
DrawableRequestBuilder<?> thumbnailRequest) {
super.thumbnail(thumbnailRequest);
return this;}
@Override
public DrawableRequestBuilder<ModelType> thumbnail(
GenericRequestBuilder<?, ?, ?, GlideDrawable> thumbnailRequest) {
super.thumbnail(thumbnailRequest);
return this;}
@Override
public DrawableRequestBuilder<ModelType> thumbnail(float sizeMultiplier) {
super.thumbnail(sizeMultiplier);
return this; }
@Override
public DrawableRequestBuilder<ModelType> sizeMultiplier(float sizeMultiplier) {
super.sizeMultiplier(sizeMultiplier);
return this; }
@Override
public DrawableRequestBuilder<ModelType> decoder(ResourceDecoder<ImageVideoWrapper, GifBitmapWrapper> decoder) {
super.decoder(decoder);
return this;}
@Override
public DrawableRequestBuilder<ModelType> cacheDecoder(ResourceDecoder<File, GifBitmapWrapper> cacheDecoder) {
super.cacheDecoder(cacheDecoder);
return this;}
@Override
public DrawableRequestBuilder<ModelType> encoder(ResourceEncoder<GifBitmapWrapper> encoder) {
super.encoder(encoder);
return this;}
@Override
public DrawableRequestBuilder<ModelType> priority(Priority priority) {
super.priority(priority);
return this;}
public DrawableRequestBuilder<ModelType> transform(BitmapTransformation... transformations) {
return bitmapTransform(transformations);}
public DrawableRequestBuilder<ModelType> centerCrop() {
return transform(glide.getDrawableCenterCrop());
}
public DrawableRequestBuilder<ModelType> fitCenter() {
return transform(glide.getDrawableFitCenter());
}
public DrawableRequestBuilder<ModelType> bitmapTransform(Transformation<Bitmap>... bitmapTransformations) {
GifBitmapWrapperTransformation[] transformations =
new GifBitmapWrapperTransformation[bitmapTransformations.length];
for (int i = 0; i < bitmapTransformations.length; i++) {
transformations[i] = new GifBitmapWrapperTransformation(glide.getBitmapPool(), bitmapTransformations[i]);
}
return transform(transformations);}
@Override
public DrawableRequestBuilder<ModelType> transform(Transformation<GifBitmapWrapper>... transformation) {
super.transform(transformation);
return this;}
@Override
public DrawableRequestBuilder<ModelType> transcoder(
ResourceTranscoder<GifBitmapWrapper, GlideDrawable> transcoder) {
super.transcoder(transcoder);
return this;}
public final DrawableRequestBuilder<ModelType> crossFade() {
super.animate(new DrawableCrossFadeFactory<GlideDrawable>());
return this;
}
public DrawableRequestBuilder<ModelType> crossFade(int duration) {
super.animate(new DrawableCrossFadeFactory<GlideDrawable>(duration));
return this;
}
public DrawableRequestBuilder<ModelType> crossFade(int animationId, int duration) {
super.animate(new DrawableCrossFadeFactory<GlideDrawable>(context, animationId,
duration));
return this;}
@Override
public DrawableRequestBuilder<ModelType> dontAnimate() {
super.dontAnimate();
return this; }
@Override
public DrawableRequestBuilder<ModelType> animate(ViewPropertyAnimation.Animator animator) {
super.animate(animator);
return this; }
@Override
public DrawableRequestBuilder<ModelType> animate(int animationId) {
super.animate(animationId);
return this;}
@Override
public DrawableRequestBuilder<ModelType> placeholder(int resourceId) {
super.placeholder(resourceId);
return this;}
@Override
public DrawableRequestBuilder<ModelType> placeholder(Drawable drawable) {
super.placeholder(drawable);
return this;}
@Override
public DrawableRequestBuilder<ModelType> fallback(Drawable drawable) {
super.fallback(drawable);
return this;}
@Override
public DrawableRequestBuilder<ModelType> fallback(int resourceId) {
super.fallback(resourceId);
return this;
}
@Override
public DrawableRequestBuilder<ModelType> error(int resourceId) {
super.error(resourceId);
return this;
}
@Override
public DrawableRequestBuilder<ModelType> error(Drawable drawable) {
super.error(drawable);
return this;
}
@Override
public DrawableRequestBuilder<ModelType> listener(
RequestListener<? super ModelType, GlideDrawable> requestListener) {
super.listener(requestListener);
return this;
}
@Override
public DrawableRequestBuilder<ModelType> diskCacheStrategy(DiskCacheStrategy strategy) {
super.diskCacheStrategy(strategy);
return this;}
@Override
public DrawableRequestBuilder<ModelType> skipMemoryCache(boolean skip) {
super.skipMemoryCache(skip);
return this; }
@Override
public DrawableRequestBuilder<ModelType> override(int width, int height) {
super.override(width, height);
return this;}
@Override
public DrawableRequestBuilder<ModelType> sourceEncoder(Encoder<ImageVideoWrapper> sourceEncoder) {
super.sourceEncoder(sourceEncoder);
return this;}
@Override
public DrawableRequestBuilder<ModelType> dontTransform() {
super.dontTransform();
return this;}
@Override
public DrawableRequestBuilder<ModelType> signature(Key signature) {
super.signature(signature);
return this;}
@Override
public DrawableRequestBuilder<ModelType> load(ModelType model) {
super.load(model);
return this;}
@Override
public DrawableRequestBuilder<ModelType> clone() {
return (DrawableRequestBuilder<ModelType>) super.clone();}
@Override
public Target<GlideDrawable> into(ImageView view) {
return super.into(view);}
@Override
void applyFitCenter() {
fitCenter(); }
@Override
void applyCenterCrop() {
centerCrop();
}
}
可以看到 DrawableRequestBuilder类的方法很多，都是直接传参数，没有什么逻辑控制，通过传参，改变了当前的成员变量的值，这也是建造者设计模式。 DrawableRequestBuilder类中的into()方法没有逻辑而是调用了一句super.into()代码，显然into()的业务逻辑是在它的父类GenericRequestBuilder中，点进去看一下源码：
public Target<TranscodeType> into(ImageView view) {
Util.assertMainThread();//主线程
if (view == null) {}
if (!isTransformationSet && view.getScaleType() != null) {
switch (view.getScaleType()) {
case CENTER_CROP:
applyCenterCrop();
break;
case FIT_CENTER:
case FIT_START:
case FIT_END:
applyFitCenter();
break;
default:
// Do nothing.
}
}
return into(glide.buildImageViewTarget(view, transcodeClass));
}
1、 buildImageViewTarget()
Util.assertMainThread()判断当前线程是不是主线程，主要就是用Looper.myLooper()与Looper.getMainLooper()做对比来确定的。into()方法参数中调用buildImageViewTarget()，这个方法会构建出一个Target对象，用来最终展示图片。
<R> Target<R> buildImageViewTarget(ImageView imageView, Class<R> transcodedClass) {
return imageViewTargetFactory.buildTarget(imageView, transcodedClass);
}
public class ImageViewTargetFactory {
@SuppressWarnings("unchecked")
public <Z> Target<Z> buildTarget(ImageView view, Class<Z> clazz) {
if (GlideDrawable.class.isAssignableFrom(clazz)) {
return (Target<Z>) new GlideDrawableImageViewTarget(view);
} else if (Bitmap.class.equals(clazz)) {
return (Target<Z>) new BitmapImageViewTarget(view);
} else if (Drawable.class.isAssignableFrom(clazz)) {
//（DrawableImageViewTarget基本上用不到，不关注它。）
return (Target<Z>) new DrawableImageViewTarget(view);
} else {
throw new IllegalArgumentException("Unhandled class: " + clazz
+ ", try .as*(Class).transcode(ResourceTranscoder)");
} }
} ImageViewTargetFactory工厂类根据不同clazz参数来构建Target对象，clazz参数有两种情况：
1、使用Glide加载图片的时候调用了asBitmap()方法，这里就会构建BitmapImageViewTarget对象。
2、默认都是生成了GlideDrawableImageViewTarget对象。
GenericRequestBuilder.into()方法将GlideDrawableImageViewTarget对象传给了它内部的into()方法：
public <Y extends Target<TranscodeType>> Y into(Y target) {
//..
Request request = buildRequest(target);//关注1
target.setRequest(request);
lifecycle.addListener(target);
requestTracker.runRequest(request);//关注2
return target;
}2、关注1 ：buildRequest 构建
buildRequest(target)是用来发出加载图片请求的，它是Glide中非常关键的一个组件，我们先来看buildRequest()方法是如何构建Request对象的：
private Request buildRequest(Target<TranscodeType> target) {
if (priority == null) {
priority = Priority.NORMAL;
}
return buildRequestRecursive(target, null);
}
private Request buildRequestRecursive(Target<TranscodeType> target, ThumbnailRequestCoordinator parentCoordinator) {
if (thumbnailRequestBuilder != null) {
if (isThumbnailBuilt) { }
if (thumbnailRequestBuilder.animationFactory.equals(NoAnimation.getFactory())) {
thumbnailRequestBuilder.animationFactory = animationFactory;
}
if (thumbnailRequestBuilder.priority == null) {
thumbnailRequestBuilder.priority = getThumbnailPriority();
}
if (Util.isValidDimensions(overrideWidth, overrideHeight)
&& !Util.isValidDimensions(thumbnailRequestBuilder.overrideWidth,
thumbnailRequestBuilder.overrideHeight)) {
thumbnailRequestBuilder.override(overrideWidth, overrideHeight);
}
ThumbnailRequestCoordinator coordinator = new ThumbnailRequestCoordinator(parentCoordinator);
Request fullRequest = obtainRequest(target, sizeMultiplier, priority, coordinator);
isThumbnailBuilt = true;
Request thumbRequest = thumbnailRequestBuilder.buildRequestRecursive(target, coordinator);
isThumbnailBuilt = false;
coordinator.setRequests(fullRequest, thumbRequest);
return coordinator;
} else if (thumbSizeMultiplier != null) {
ThumbnailRequestCoordinator coordinator = new ThumbnailRequestCoordinator(parentCoordinator);
Request fullRequest = obtainRequest(target, sizeMultiplier, priority, coordinator);
Request thumbnailRequest = obtainRequest(target, thumbSizeMultiplier, getThumbnailPriority(), coordinator);
coordinator.setRequests(fullRequest, thumbnailRequest);
return coordinator;
} else {
//注释1
return obtainRequest(target, sizeMultiplier, priority, parentCoordinator);
}
}
这里主要是在处理缩略图的。最后“注释1”处调用了obtainRequest()方法来获取一个Request对象，而obtainRequest()方法中又去调用了GenericRequest的obtain()方法。代码如下：
private Request obtainRequest(Target<TranscodeType> target, float sizeMultiplier, Priority priority,
RequestCoordinator requestCoordinator) {
return GenericRequest.obtain(
loadProvider,
model,
signature,
context,
priority,
target,
sizeMultiplier,
placeholderDrawable,
placeholderId,
errorPlaceholder,
errorId,
fallbackDrawable,
fallbackResource,
requestListener,
requestCoordinator,
glide.getEngine(),
transformation,
transcodeClass,
isCacheable,
animationFactory,
overrideWidth,
overrideHeight,
diskCacheStrategy);
}注意obtain()方法需要传入非常多的参数，而其中很多的参数我们都是比较熟悉的，像什么placeholderId、errorPlaceholder、diskCacheStrategy等等。因此，我们就有理由猜测，刚才在load()方法中调用的所有API，其实都是在这里组装到Request对象当中的。那么我们进入到这个GenericRequest.obtain()方法看看。
public final class GenericRequest<A, T, Z, R> implements Request, SizeReadyCallback,
ResourceCallback {
public static <A, T, Z, R> GenericRequest<A, T, Z, R> obtain(
LoadProvider<A, T, Z, R> loadProvider,
A model,
Key signature,
Context context,
Priority priority,
Target<R> target,
float sizeMultiplier,
Drawable placeholderDrawable,
int placeholderResourceId,
Drawable errorDrawable,
int errorResourceId,
Drawable fallbackDrawable,
int fallbackResourceId,
RequestListener<? super A, R> requestListener,
RequestCoordinator requestCoordinator,
Engine engine,
Transformation<Z> transformation,
Class<R> transcodeClass,
boolean isMemoryCacheable,
GlideAnimationFactory<R> animationFactory,
int overrideWidth,
int overrideHeight,
DiskCacheStrategy diskCacheStrategy) {
@SuppressWarnings("unchecked")
GenericRequest<A, T, Z, R> request = (GenericRequest<A, T, Z, R>) REQUEST_POOL.poll();
if (request == null) {
request = new GenericRequest<A, T, Z, R>();
}
request.init(loadProvider,
model,
signature,
context,
priority,
target,
sizeMultiplier,
placeholderDrawable,
placeholderResourceId,
errorDrawable,
errorResourceId,
fallbackDrawable,
fallbackResourceId,
requestListener,
requestCoordinator,
engine,
transformation,
transcodeClass,
isMemoryCacheable,
animationFactory,
overrideWidth,
overrideHeight,
diskCacheStrategy);
return request;
}
...
}
obtain()方法实际上获得的就是一个GenericRequest对象，代码中创建了GenericRequest对象，并放到return中。GenericRequest的init()，里面主要就是一些赋值的代码，将传入的这些参数赋值到GenericRequest的成员变量当中。
到这里基本解决了构建Request对象的问题，接下来我们看一下这个Request对象又是怎么执行的。回到前面说的into()方法最后调用了requestTracker.runRequest()方法来去执行这个Request。如下所示：
3、关注2：runRequest 执行
public void runRequest(Request request) {
requests.add(request);
if (!isPaused) {
request.begin();
} else {
pendingRequests.add(request);
}
}
这里先判断Glide当前是不是Paused(暂停)状态，如果不是就调用Request.begin()方法去执行，否则就先将Request对象添加到待执行队列里面，等暂停状态解除后再执行。我们重点来看这个begin()方法。由于当前的Request对象是一个GenericRequest，因此这里是GenericRequest.begin()，如下所示：
public abstract class ImageViewTarget<Z> extends ViewTarget<ImageView, Z> implements GlideAnimation.ViewAdapter {
...
@Override
public void onLoadStarted(Drawable placeholder) {//显示占位图
view.setImageDrawable(placeholder);
}
@Override
public void onLoadFailed(Exception e, Drawable errorDrawable) {//显示错误图
view.setImageDrawable(errorDrawable);
}
...
}
@Override
public void begin() {
startTime = LogTime.getLogTime();
if (model == null) {
onException(null);
return;
}
status = Status.WAITING_FOR_SIZE;
if (Util.isValidDimensions(overrideWidth, overrideHeight)) {
onSizeReady(overrideWidth, overrideHeight);
} else {
target.getSize(this);
}
if (!isComplete() && !isFailed() && canNotifyStatusChanged()) {
target.onLoadStarted(getPlaceholderDrawable());
}
}model是load()方法中传入的图片URL地址。如果model等于null，会调用onException()方法。如果你跟到onException()方法里面最终会调用到一个setErrorPlaceholder()，设置错误占位图。
private void setErrorPlaceholder(Exception e) {
if (!canNotifyStatusChanged()) {
return;
}
Drawable error = model == null ? getFallbackDrawable() : null;
if (error == null) {
error = getErrorDrawable();
}
if (error == null) {
error = getPlaceholderDrawable();
}
target.onLoadFailed(e, error);
}
当出现了异常，没办法展示正常的图片了，将error占位图显示到ImageView上。
再说回begin()方法，它最后调用了target.onLoadStarted()方法，并传入了一个loading占位图，在图片请求开始之前，会先使用这张占位图代替最终的图片显示。这就是Glide的placeholder()和 error()这两个占位图API底层的实现原理。
上面begin（）方法中还调用了
onSizeReady(overrideWidth, overrideHeight);和target.getSize(this);。这里要分两种情况，一种是手动为图片指定了宽高，一种是没有指定。如果指定了的话，就会执行onSizeReady()方法。如果没指定的话，就会执行target.getSize()方法。这个target.getSize()方法的内部会根据ImageView控件的layout_width和layout_height值做一系列的计算，来算出图片对应的宽高，总之在计算完之后，最终还是会调用onSizeReady()方法。如下。
@Override
public void onSizeReady(int width, int height) {
if (Log.isLoggable(TAG, Log.VERBOSE)) {}
if (status != Status.WAITING_FOR_SIZE) {
return;
}
status = Status.RUNNING;
width = Math.round(sizeMultiplier * width);
height = Math.round(sizeMultiplier * height);
ModelLoader<A, T> modelLoader = loadProvider.getModelLoader();
final DataFetcher<T> dataFetcher = modelLoader.getResourceFetcher(model, width, height);
if (dataFetcher == null) {
return;
}
ResourceTranscoder<Z, R> transcoder = loadProvider.getTranscoder();
loadedFromMemoryCache = true;
loadStatus = engine.load(signature, width, height, dataFetcher, loadProvider, transformation, transcoder,
priority, isMemoryCacheable, diskCacheStrategy, this);
loadedFromMemoryCache = resource != null;
}
这里分别调用了loadProvider的getModelLoader()方法和getTranscoder()方法，他们会得到ImageVideoModelLoader和GifBitmapWrapperDrawableTranscoder。最后调用engine.load()，源码如下：
public class Engine implements EngineJobListener,
MemoryCache.ResourceRemovedListener,
EngineResource.ResourceListener {
public <T, Z, R> LoadStatus load(Key signature, int width, int height, DataFetcher<T> fetcher,
DataLoadProvider<T, Z> loadProvider, Transformation<Z> transformation, ResourceTranscoder<Z, R> transcoder,
Priority priority, boolean isMemoryCacheable, DiskCacheStrategy diskCacheStrategy, ResourceCallback cb) {
Util.assertMainThread();
long startTime = LogTime.getLogTime();
final String id = fetcher.getId();
EngineKey key = keyFactory.buildKey(id, signature, width, height, loadProvider.getCacheDecoder(),
loadProvider.getSourceDecoder(), transformation, loadProvider.getEncoder(),
transcoder, loadProvider.getSourceEncoder());
EngineResource<?> cached = loadFromCache(key, isMemoryCacheable);
if (cached != null) {
cb.onResourceReady(cached);
return null;
}
EngineResource<?> active = loadFromActiveResources(key, isMemoryCacheable);
if (active != null) {
cb.onResourceReady(active);
return null;
}
EngineJob current = jobs.get(key);
if (current != null) {
current.addCallback(cb);
if (Log.isLoggable(TAG, Log.VERBOSE)) {
logWithTimeAndKey("Added to existing load", startTime, key);
}
return new LoadStatus(cb, current);
}
EngineJob engineJob = engineJobFactory.build(key, isMemoryCacheable);
DecodeJob<T, Z, R> decodeJob = new DecodeJob<T, Z, R>(key, width, height, fetcher, loadProvider, transformation,
transcoder, diskCacheProvider, diskCacheStrategy, priority);
EngineRunnable runnable = new EngineRunnable(engineJob, decodeJob, priority);
jobs.put(key, engineJob);
engineJob.addCallback(cb);
engineJob.start(runnable);
return new LoadStatus(cb, engineJob);
}
}
最后调用了 engineJob.start(runnable); 跟踪代码看看这个EngineRunnable的run()方法做了什么
@Override
public void run() {
if (isCancelled) {
return;
}
Exception exception = null;
Resource<?> resource = null;
try {
resource = decode();
} catch (Exception e) {
exception = e;
}
if (isCancelled) {
if (resource != null) {
resource.recycle();
}
return;
}
if (resource == null) {
onLoadFailed(exception);
} else {
onLoadComplete(resource);
}
}
private Resource<?> decode() throws Exception {
if (isDecodingFromCache()) {
return decodeFromCache();
} else {
return decodeFromSource();
}
}
private Resource<?> decodeFromSource() throws Exception {
return decodeJob.decodeFromSource();
}
这里主要调用了一个decode()方法，并且这个方法返回了一个Resource对象。decode()方法中又分了两种情况，从缓存当中去decode图片的话就会执行decodeFromCache()，否则的话就执行decodeFromSource()，之后又调用了DecodeJob的decodeFromSource()方法。看一下DecodeJob源码：
class DecodeJob<A, T, Z> {
public Resource<Z> decodeFromSource() throws Exception {
Resource<T> decoded = decodeSource();
return transformEncodeAndTranscode(decoded);
}
private Resource<T> decodeSource() throws Exception {
Resource<T> decoded = null;
try {
long startTime = LogTime.getLogTime();
final A data = fetcher.loadData(priority);
if (isCancelled) {
return null;
}
decoded = decodeFromSourceData(data);
} finally {
fetcher.cleanup();
}
return decoded;
}
}
它的工作分为两部，第一步是调用decodeSource()方法来获得一个Resource对象，第二步是调用transformEncodeAndTranscode()方法来处理这个Resource对象。
那么我们先来看第一步，decodeSource()方法中的逻辑也并不复杂，首先调用了fetcher.loadData()方法。那么这个fetcher是什么呢？其实就是刚才在onSizeReady()方法中得到的ImageVideoFetcher对象，这里调用它的loadData()方法，代码如下所示：
@Override
public ImageVideoWrapper loadData(Priority priority) throws Exception {
InputStream is = null;
if (streamFetcher != null) {
try {
is = streamFetcher.loadData(priority);
} catch (Exception e) {
if (fileDescriptorFetcher == null) {
throw e;
}
}
}
ParcelFileDescriptor fileDescriptor = null;
if (fileDescriptorFetcher != null) {
try {
fileDescriptor = fileDescriptorFetcher.loadData(priority);
} catch (Exception e) {
if (is == null) {
throw e;
}
}
}
return new ImageVideoWrapper(is, fileDescriptor);
}
在ImageVideoFetcher的loadData()方调用了streamFetcher.loadData()方法。那么这个streamFetcher是什么呢？自然就是刚才在组装ImageVideoFetcher对象时传进来的HttpUrlFetcher了。因此这里又会去调用HttpUrlFetcher的loadData()方法。
public class HttpUrlFetcher implements DataFetcher<InputStream> {
@Override
public InputStream loadData(Priority priority) throws Exception {
return loadDataWithRedirects(glideUrl.toURL(), 0 /*redirects*/, null /*lastUrl*/, glideUrl.getHeaders());
}
private InputStream loadDataWithRedirects(URL url, int redirects, URL lastUrl, Map<String, String> headers)
throws IOException {
if (redirects >= MAXIMUM_REDIRECTS) {
throw new IOException("Too many (> " + MAXIMUM_REDIRECTS + ") redirects!");
} else {
//..
}
urlConnection = connectionFactory.build(url);
for (Map.Entry<String, String> headerEntry : headers.entrySet()) {
urlConnection.addRequestProperty(headerEntry.getKey(), headerEntry.getValue());
}
urlConnection.setConnectTimeout(2500);
urlConnection.setReadTimeout(2500);
urlConnection.setUseCaches(false);
urlConnection.setDoInput(true);
urlConnection.connect();
if (isCancelled) {
return null;
}
final int statusCode = urlConnection.getResponseCode();
if (statusCode / 100 == 2) {
return getStreamForSuccessfulRequest(urlConnection);
} else if (statusCode / 100 == 3) {
String redirectUrlString = urlConnection.getHeaderField("Location");
if (TextUtils.isEmpty(redirectUrlString)) {
throw new IOException("Received empty or null redirect url");
}
URL redirectUrl = new URL(url, redirectUrlString);
return loadDataWithRedirects(redirectUrl, redirects + 1, url, headers);
} else {
//..
}
}
private InputStream getStreamForSuccessfulRequest(HttpURLConnection urlConnection)
throws IOException {
if (TextUtils.isEmpty(urlConnection.getContentEncoding())) {
int contentLength = urlConnection.getContentLength();
stream = ContentLengthInputStream.obtain(urlConnection.getInputStream(), contentLength);
} else {
if (Log.isLoggable(TAG, Log.DEBUG)) {
Log.d(TAG, "Got non empty content encoding: " + urlConnection.getContentEncoding());
}
stream = urlConnection.getInputStream();
}
return stream;
}
}
可以看到，loadData()方法只是返回了一个InputStream，服务器返回的数据连读都还没开始读呢。所以我们还是要静下心来继续分析，回到刚才ImageVideoFetcher的loadData()方法中，在这个方法的最后一行，创建了一个ImageVideoWrapper对象，并把刚才得到的InputStream作为参数传了进去。然后我们回到再上一层，也就是DecodeJob的decodeSource()方法当中，在得到了这个ImageVideoWrapper对象之后，紧接着又将这个对象传入到了decodeFromSourceData()当中，来去解码这个对象。decodeFromSourceData()方法的代码如下所示。
private Resource<T> decodeFromSourceData(A data) throws IOException {
final Resource<T> decoded;
if (diskCacheStrategy.cacheSource()) {
decoded = cacheAndDecodeSourceData(data);
} else {
long startTime = LogTime.getLogTime();
decoded = loadProvider.getSourceDecoder().decode(data, width, height);
if (Log.isLoggable(TAG, Log.VERBOSE)) {
logWithTimeAndKey("Decoded from source", startTime);
}
}
return decoded;
}
这里调用了loadProvider.getSourceDecoder().decode()方法来进行解码。loadProvider就是刚才在onSizeReady()方法中得到的FixedLoadProvider，而getSourceDecoder()得到的则是一个GifBitmapWrapperResourceDecoder对象，也就是要调用这个对象的decode()方法来对图片进行解码。那么我们来看下GifBitmapWrapperResourceDecoder的代码：
public class GifBitmapWrapperResourceDecoder implements ResourceDecoder<ImageVideoWrapper, GifBitmapWrapper> {
@SuppressWarnings("resource")
// @see ResourceDecoder.decode
@Override
public Resource<GifBitmapWrapper> decode(ImageVideoWrapper source, int width, int height) throws IOException {
ByteArrayPool pool = ByteArrayPool.get();
byte[] tempBytes = pool.getBytes();
GifBitmapWrapper wrapper = null;
try {
wrapper = decode(source, width, height, tempBytes);
} finally {
pool.releaseBytes(tempBytes);
}
return wrapper != null ? new GifBitmapWrapperResource(wrapper) : null;
}
private GifBitmapWrapper decode(ImageVideoWrapper source, int width, int height, byte[] bytes) throws IOException {
final GifBitmapWrapper result;
if (source.getStream() != null) {
result = decodeStream(source, width, height, bytes);
} else {
result = decodeBitmapWrapper(source, width, height);
}
return result;
}
private GifBitmapWrapper decodeStream(ImageVideoWrapper source, int width, int height, byte[] bytes)
throws IOException {
InputStream bis = streamFactory.build(source.getStream(), bytes);
bis.mark(MARK_LIMIT_BYTES);
ImageHeaderParser.ImageType type = parser.parse(bis);
bis.reset();
GifBitmapWrapper result = null;
if (type == ImageHeaderParser.ImageType.GIF) {
result = decodeGifWrapper(bis, width, height);
}
if (result == null) {
ImageVideoWrapper forBitmapDecoder = new ImageVideoWrapper(bis, source.getFileDescriptor());
result = decodeBitmapWrapper(forBitmapDecoder, width, height);
}
return result;
}
private GifBitmapWrapper decodeBitmapWrapper(ImageVideoWrapper toDecode, int width, int height) throws IOException {
GifBitmapWrapper result = null;
Resource<Bitmap> bitmapResource = bitmapDecoder.decode(toDecode, width, height);
if (bitmapResource != null) {
result = new GifBitmapWrapper(bitmapResource, null);
}
return result;
}
}
首先，在decode()方法中，又去调用了另外一个decode()方法的重载。然后调用了decodeStream()方法，准备从服务器返回的流当中读取数据。decodeStream()方法中会先从流中读取2个字节的数据，来判断这张图是GIF图还是普通的静图，如果是GIF图就调用decodeGifWrapper()方法来进行解码，如果是普通的静图就用调用decodeBitmapWrapper()方法来进行解码。这里我们只分析普通静图的实现流程，GIF图的实现有点过于复杂了，无法在本篇文章当中分析。
然后我们来看一下decodeBitmapWrapper()方法，这里调用了bitmapDecoder.decode()方法。这个bitmapDecoder是一个ImageVideoBitmapDecoder对象，那么我们来看一下它的代码，如下所示：
public class ImageVideoBitmapDecoder implements ResourceDecoder<ImageVideoWrapper, Bitmap> {
private final ResourceDecoder<InputStream, Bitmap> streamDecoder;
private final ResourceDecoder<ParcelFileDescriptor, Bitmap> fileDescriptorDecoder;
public ImageVideoBitmapDecoder(ResourceDecoder<InputStream, Bitmap> streamDecoder,
ResourceDecoder<ParcelFileDescriptor, Bitmap> fileDescriptorDecoder) {
this.streamDecoder = streamDecoder;
this.fileDescriptorDecoder = fileDescriptorDecoder;
}
@Override
public Resource<Bitmap> decode(ImageVideoWrapper source, int width, int height) throws IOException {
Resource<Bitmap> result = null;
InputStream is = source.getStream();
if (is != null) {
try {
result = streamDecoder.decode(is, width, height);
} catch (IOException e) {//..
}
}
if (result == null) {
ParcelFileDescriptor fileDescriptor = source.getFileDescriptor();
if (fileDescriptor != null) {
result = fileDescriptorDecoder.decode(fileDescriptor, width, height);
}
}
return result;
}
}
上面调用了source.getStream()来获取到服务器返回的InputStream，然后调用streamDecoder.decode()方法进行解码。streamDecode是一个StreamBitmapDecoder对象，那么我们再来看这个类的源码，如下所示：
public class StreamBitmapDecoder implements ResourceDecoder<InputStream, Bitmap> {
private final Downsampler downsampler;
private BitmapPool bitmapPool;
private DecodeFormat decodeFormat;
public StreamBitmapDecoder(Downsampler downsampler, BitmapPool bitmapPool, DecodeFormat decodeFormat) {
this.downsampler = downsampler;
this.bitmapPool = bitmapPool;
this.decodeFormat = decodeFormat;
}
@Override
public Resource<Bitmap> decode(InputStream source, int width, int height) {
Bitmap bitmap = downsampler.decode(source, bitmapPool, width, height, decodeFormat);
return BitmapResource.obtain(bitmap, bitmapPool);
}
}
当然这里其实处理了很多的逻辑，包括对图片的压缩，甚至还有旋转、圆角等逻辑处理，但是我们目前只需要关注主线逻辑就行了。decode()方法执行之后，会返回一个Bitmap对象，那么图片在这里其实也就已经被加载出来了，剩下的工作就是如果让这个Bitmap显示到界面上。回到刚才的StreamBitmapDecoder当中，你会发现，它的decode()方法返回的是一个Resource<Bitmap>对象。而我们从Downsampler中得到的是一个Bitmap对象，因此这里又调用了BitmapResource.obtain()方法，将Bitmap对象包装成了Resource<Bitmap>对象。代码如下所示：
public class BitmapResource implements Resource<Bitmap> {
private final Bitmap bitmap;
private final BitmapPool bitmapPool;
public static BitmapResource obtain(Bitmap bitmap, BitmapPool bitmapPool) {
if (bitmap == null) {
return null;
} else {
return new BitmapResource(bitmap, bitmapPool);
}
}
public BitmapResource(Bitmap bitmap, BitmapPool bitmapPool) {
if (bitmap == null) {
throw new NullPointerException("Bitmap must not be null");
}
if (bitmapPool == null) {
throw new NullPointerException("BitmapPool must not be null");
}
this.bitmap = bitmap;
this.bitmapPool = bitmapPool;
}
@Override
public Bitmap get() {
return bitmap;
}
@Override
public int getSize() {
return Util.getBitmapByteSize(bitmap);
}
@Override
public void recycle() {
if (!bitmapPool.put(bitmap)) {
bitmap.recycle();
}
}
}
BitmapResource的源码也非常简单，经过这样一层包装之后，如果我还需要获取Bitmap，只需要调用Resource<Bitmap>的get()方法就可以了。然后我们需要一层层继续向上返回，StreamBitmapDecoder会将值返回到ImageVideoBitmapDecoder当中，而ImageVideoBitmapDecoder又会将值返回到GifBitmapWrapperResourceDecoder的decodeBitmapWrapper()方法当中。由于代码隔得有点太远了，我重新把decodeBitmapWrapper()方法的代码贴一下：
private GifBitmapWrapper decodeBitmapWrapper(ImageVideoWrapper toDecode, int width, int height) throws IOException {
GifBitmapWrapper result = null;
Resource<Bitmap> bitmapResource = bitmapDecoder.decode(toDecode, width, height);
if (bitmapResource != null) {
result = new GifBitmapWrapper(bitmapResource, null);
}
return result;
}
可以看到，decodeBitmapWrapper()方法返回的是一个GifBitmapWrapper对象。因此，这里又将Resource<Bitmap>封装到了一个GifBitmapWrapper对象当中。这个GifBitmapWrapper顾名思义，就是既能封装GIF，又能封装Bitmap，从而保证了不管是什么类型的图片Glide都能从容应对。我们顺便来看下GifBitmapWrapper的源码吧，如下所示：
public class GifBitmapWrapper {
private final Resource<GifDrawable> gifResource;
private final Resource<Bitmap> bitmapResource;
public GifBitmapWrapper(Resource<Bitmap> bitmapResource, Resource<GifDrawable> gifResource) {
if (bitmapResource != null && gifResource != null) {
throw new IllegalArgumentException("Can only contain either a bitmap resource or a gif resource, not both");
}
if (bitmapResource == null && gifResource == null) {
throw new IllegalArgumentException("Must contain either a bitmap resource or a gif resource");
}
this.bitmapResource = bitmapResource;
this.gifResource = gifResource;
}
public int getSize() {
if (bitmapResource != null) {
return bitmapResource.getSize();
} else {
return gifResource.getSize();
}
}
public Resource<Bitmap> getBitmapResource() {
return bitmapResource;
}
public Resource<GifDrawable> getGifResource() {
return gifResource;
}
}
还是比较简单的，就是分别对gifResource和bitmapResource做了一层封装而已，相信没有什么解释的必要。
然后，这个GifBitmapWrapper对象会一直向上返回，返回到GifBitmapWrapperResourceDecoder最外层的decode()方法的时候，会对它再做一次封装，如下所示：
@Override
public Resource<GifBitmapWrapper> decode(ImageVideoWrapper source, int width, int height) throws IOException {
ByteArrayPool pool = ByteArrayPool.get();
byte[] tempBytes = pool.getBytes();
GifBitmapWrapper wrapper = null;
try {
wrapper = decode(source, width, height, tempBytes);
} finally {
pool.releaseBytes(tempBytes);
}
return wrapper != null ? new GifBitmapWrapperResource(wrapper) : null;
}
可以看到，这里又将GifBitmapWrapper封装到了一个GifBitmapWrapperResource对象当中，最终返回的是一个Resource<GifBitmapWrapper>对象。这个GifBitmapWrapperResource和刚才的BitmapResource是相似的，它们都实现的Resource接口，都可以通过get()方法来获取封装起来的具体内容。GifBitmapWrapperResource的源码如下所示：
public class GifBitmapWrapperResource implements Resource<GifBitmapWrapper> {
private final GifBitmapWrapper data;
public GifBitmapWrapperResource(GifBitmapWrapper data) {
if (data == null) {
throw new NullPointerException("Data must not be null");
}
this.data = data;
}
@Override
public GifBitmapWrapper get() {
return data;
}
@Override
public int getSize() {
return data.getSize();
}
@Override
public void recycle() {
Resource<Bitmap> bitmapResource = data.getBitmapResource();
if (bitmapResource != null) {
bitmapResource.recycle();
}
Resource<GifDrawable> gifDataResource = data.getGifResource();
if (gifDataResource != null) {
gifDataResource.recycle();
}
}
}
经过这一层的封装之后，我们从网络上得到的图片就能够以Resource接口的形式返回，并且还能同时处理Bitmap图片和GIF图片这两种情况。
现在回到DecodeJob，它的decodeFromSourceData()方法返回的是一个Resource<T>对象，其实也就是Resource<GifBitmapWrapper>对象。然后继续向上返回，最终返回到decodeFromSource()方法当中，如下所示。
public Resource<Z> decodeFromSource() throws Exception {
Resource<T> decoded = decodeSource();
return transformEncodeAndTranscode(decoded);
}
刚才我们就是从这里跟进到decodeSource()方法当中，然后执行了一大堆一大堆的逻辑，最终得到了这个Resource<T>对象。然而你会发现，decodeFromSource()方法最终返回的却是一个Resource<Z>对象，那么这到底是怎么回事呢？我们就需要跟进到transformEncodeAndTranscode()方法来瞧一瞧了，代码如下所示：
private Resource<Z> transformEncodeAndTranscode(Resource<T> decoded) {
long startTime = LogTime.getLogTime();
Resource<T> transformed = transform(decoded);
writeTransformedToCache(transformed);
startTime = LogTime.getLogTime();
Resource<Z> result = transcode(transformed);
return result;
}
private Resource<Z> transcode(Resource<T> transformed) {
if (transformed == null) {
return null;
}
return transcoder.transcode(transformed);
}
首先，这里调用了一个transcode()方法，就把Resource<T>对象转换成Resource<Z>对象。而transcode()方法中又是调用了transcoder.transcode()，那么这个transcoder是什么呢？就是在第二步load()方法返回的那个DrawableTypeRequest对象，它的构建函数中去构建了一个FixedLoadProvider对象，然后我们将三个参数传入到了FixedLoadProvider当中，其中就有一个GifBitmapWrapperDrawableTranscoder对象。后来在onSizeReady()方法中获取到了这个参数，并传递到了Engine当中，然后又由Engine传递到了DecodeJob当中。因此，这里的transcoder其实就是这个GifBitmapWrapperDrawableTranscoder对象。那么我们来看一下它的源码：
public class GifBitmapWrapperDrawableTranscoder implements ResourceTranscoder<GifBitmapWrapper, GlideDrawable> {
private final ResourceTranscoder<Bitmap, GlideBitmapDrawable> bitmapDrawableResourceTranscoder;
public GifBitmapWrapperDrawableTranscoder(
ResourceTranscoder<Bitmap, GlideBitmapDrawable> bitmapDrawableResourceTranscoder) {
this.bitmapDrawableResourceTranscoder = bitmapDrawableResourceTranscoder;
}
@Override
public Resource<GlideDrawable> transcode(Resource<GifBitmapWrapper> toTranscode) {
GifBitmapWrapper gifBitmap = toTranscode.get();
Resource<Bitmap> bitmapResource = gifBitmap.getBitmapResource();
final Resource<? extends GlideDrawable> result;
if (bitmapResource != null) {
result = bitmapDrawableResourceTranscoder.transcode(bitmapResource);
} else {
result = gifBitmap.getGifResource();
}
return (Resource<GlideDrawable>) result;
}
}
GifBitmapWrapperDrawableTranscoder的核心作用就是用来转码的。因为GifBitmapWrapper是无法直接显示到ImageView上面的，只有Bitmap或Drawable才能显示到ImageView上。因此，这里的transcode()方法先从Resource<GifBitmapWrapper>中取出GifBitmapWrapper对象，然后再从GifBitmapWrapper中取出Resource<Bitmap>对象。然后判断，如果Resource<Bitmap>为空，那么说明此时加载的是GIF图，直接调用getGifResource()方法将图片取出即可，因为Glide用于加载GIF图片是使用的GifDrawable这个类，它本身就是一个Drawable对象了。而如果Resource<Bitmap>不为空，那么就需要再做一次转码，将Bitmap转换成Drawable对象才行，因为要保证静图和动图的类型一致性，不然逻辑上是不好处理的。这里又进行了一次转码，是调用的GlideBitmapDrawableTranscoder对象的transcode()方法，代码如下所示：
public class GlideBitmapDrawableTranscoder implements ResourceTranscoder<Bitmap, GlideBitmapDrawable> {
private final Resources resources;
private final BitmapPool bitmapPool;
/..
@Override
public Resource<GlideBitmapDrawable> transcode(Resource<Bitmap> toTranscode) {
GlideBitmapDrawable drawable = new GlideBitmapDrawable(resources, toTranscode.get());
return new GlideBitmapDrawableResource(drawable, bitmapPool);
}
}
可以看到，这里new了一个GlideBitmapDrawable对象，并把Bitmap封装到里面。然后对GlideBitmapDrawable再进行一次封装，返回一个Resource<GlideBitmapDrawable>对象。现在再返回到GifBitmapWrapperDrawableTranscoder的transcode()方法中，你会发现它们的类型就一致了。因为不管是静图的Resource<GlideBitmapDrawable>对象，还是动图的Resource<GifDrawable>对象，它们都是属于父类Resource<GlideDrawable>对象的。因此transcode()方法也是直接返回了Resource<GlideDrawable>，而这个Resource<GlideDrawable>其实也就是转换过后的Resource<Z>了。
继续回到DecodeJob，它的decodeFromSource()方法得到了Resource<Z>对象，当然也就是Resource<GlideDrawable>对象。然后继续向上返回会回到EngineRunnable的decodeFromSource()方法，再回到decode()方法，再回到run()方法当中。那么我们重新再贴一下EngineRunnable run()方法的源码：
@Override
public void run() {
if (isCancelled) {
return;
}
Exception exception = null;
Resource<?> resource = null;
try {
resource = decode();
} catch (Exception e) {
if (Log.isLoggable(TAG, Log.VERBOSE)) {
Log.v(TAG, "Exception decoding", e);
}
exception = e;
}
if (isCancelled) {
if (resource != null) {
resource.recycle();
}
return;
}
if (resource == null) {
onLoadFailed(exception);
} else {
onLoadComplete(resource);
}
}
也就是说，经过decode()方法的执行，我们最终得到了这个Resource<GlideDrawable>对象，那么接下来就是如何将它显示出来了。可以看到，这里调用了onLoadComplete()方法，表示图片加载已经完成了，代码如下所示：
class EngineJob implements EngineRunnable.EngineRunnableManager {
private static final Handler MAIN_THREAD_HANDLER = new Handler(Looper.getMainLooper(), new MainThreadCallback());
private final List<ResourceCallback> cbs = new ArrayList<ResourceCallback>();
public void addCallback(ResourceCallback cb) {
Util.assertMainThread();
if (hasResource) {
cb.onResourceReady(engineResource);
} else if (hasException) {
cb.onException(exception);
} else {
cbs.add(cb);
}
}
@Override
public void onResourceReady(final Resource<?> resource) {
this.resource = resource;
MAIN_THREAD_HANDLER.obtainMessage(MSG_COMPLETE, this).sendToTarget();
}
private void handleResultOnMainThread() {
if (isCancelled) {
resource.recycle();
return;
} else if (cbs.isEmpty()) {
throw new IllegalStateException("Received a resource without any callbacks to notify");
}
engineResource = engineResourceFactory.build(resource, isCacheable);
hasResource = true;
engineResource.acquire();
listener.onEngineJobComplete(key, engineResource);
for (ResourceCallback cb : cbs) {
if (!isInIgnoredCallbacks(cb)) {
engineResource.acquire();
cb.onResourceReady(engineResource);
}
}
engineResource.release();
}
@Override
public void onException(final Exception e) {
this.exception = e;
MAIN_THREAD_HANDLER.obtainMessage(MSG_EXCEPTION, this).sendToTarget();
}
private void handleExceptionOnMainThread() {
if (isCancelled) {
return;
} else if (cbs.isEmpty()) {
throw new IllegalStateException("Received an exception without any callbacks to notify");
}
hasException = true;
listener.onEngineJobComplete(key, null);
for (ResourceCallback cb : cbs) {
if (!isInIgnoredCallbacks(cb)) {
cb.onException(exception);
}
}
}
private static class MainThreadCallback implements Handler.Callback {
@Override
public boolean handleMessage(Message message) {
if (MSG_COMPLETE == message.what || MSG_EXCEPTION == message.what) {
EngineJob job = (EngineJob) message.obj;
if (MSG_COMPLETE == message.what) {
job.handleResultOnMainThread();
} else {
job.handleExceptionOnMainThread();
}
return true;
}
return false;
}
}
}
可以看到，这里在onResourceReady()方法使用Handler发出了一条MSG_COMPLETE消息，那么在MainThreadCallback的handleMessage()方法中就会收到这条消息。从这里开始，所有的逻辑又回到主线程当中进行了，因为很快就需要更新UI了。然后，调用了handleResultOnMainThread()方法，这个方法中又通过一个循环，调用了所有ResourceCallback的onResourceReady()方法。那么这个ResourceCallback是什么呢？答案在addCallback()方法当中，它会向cbs集合中去添加ResourceCallback。那么这个addCallback()方法又是哪里调用的呢？其实调用的地方我们早就已经看过了，只不过之前没有注意，现在重新来看一下Engine的load()方法，如下所示：
public class Engine implements EngineJobListener,
MemoryCache.ResourceRemovedListener,
EngineResource.ResourceListener {
public <T, Z, R> LoadStatus load(Key signature, int width, int height, DataFetcher<T> fetcher,
DataLoadProvider<T, Z> loadProvider, Transformation<Z> transformation, ResourceTranscoder<Z, R> transcoder, Priority priority,
boolean isMemoryCacheable, DiskCacheStrategy diskCacheStrategy, ResourceCallback cb) {
EngineJob engineJob = engineJobFactory.build(key, isMemoryCacheable);
DecodeJob<T, Z, R> decodeJob = new DecodeJob<T, Z, R>(key, width, height, fetcher, loadProvider, transformation,
transcoder, diskCacheProvider, diskCacheStrategy, priority);
EngineRunnable runnable = new EngineRunnable(engineJob, decodeJob, priority);
jobs.put(key, engineJob);
engineJob.addCallback(cb);
engineJob.start(runnable);
if (Log.isLoggable(TAG, Log.VERBOSE)) {
logWithTimeAndKey("Started new load", startTime, key);
}
return new LoadStatus(cb, engineJob);
}
}
注意EngineJob.addCallback()方法来注册的一个ResourceCallback。那么接下来的问题就是，Engine.load()方法的ResourceCallback参数又是谁传过来的呢？这就需要回到GenericRequest的onSizeReady()方法当中了，我们看到ResourceCallback是load()方法的最后一个参数，那么在onSizeReady()方法中调用load()方法时传入的最后一个参数是什么？代码如下所示：
public final class GenericRequest<A, T, Z, R> implements Request, SizeReadyCallback,
ResourceCallback {
@Override
public void onSizeReady(int width, int height) {
if (status != Status.WAITING_FOR_SIZE) {
return;
}
status = Status.RUNNING;
width = Math.round(sizeMultiplier * width);
height = Math.round(sizeMultiplier * height);
ModelLoader<A, T> modelLoader = loadProvider.getModelLoader();
final DataFetcher<T> dataFetcher = modelLoader.getResourceFetcher(model, width, height);
ResourceTranscoder<Z, R> transcoder = loadProvider.getTranscoder();
loadedFromMemoryCache = true;
loadStatus = engine.load(signature, width, height, dataFetcher, loadProvider, transformation,
transcoder, priority, isMemoryCacheable, diskCacheStrategy, this);
loadedFromMemoryCache = resource != null;
}
}
GenericRequest本身就实现了ResourceCallback的接口，因此EngineJob的回调最终其实就是回调到了GenericRequest的onResourceReady()方法当中了，代码如下所示：
public void onResourceReady(Resource<?> resource) {
Object received = resource.get();
if (received == null || !transcodeClass.isAssignableFrom(received.getClass())) {
releaseResource(resource);
return;
}
if (!canSetResource()) {
releaseResource(resource);
status = Status.COMPLETE;
return;
}
onResourceReady(resource, (R) received);
}
private void onResourceReady(Resource<?> resource, R result) {
boolean isFirstResource = isFirstReadyResource();
status = Status.COMPLETE;
this.resource = resource;
if (requestListener == null || !requestListener.onResourceReady(result, model, target, loadedFromMemoryCache,
isFirstResource)) {
GlideAnimation<R> animation = animationFactory.build(loadedFromMemoryCache, isFirstResource);
target.onResourceReady(result, animation);
}
notifyLoadSuccess();
}
这里有两个onResourceReady()方法，首先在第一个onResourceReady()方法当中，调用resource.get()方法获取到了封装的图片对象，也就是GlideBitmapDrawable对象，或者是GifDrawable对象。然后将这个值传入到了第二个onResourceReady()方法当中，并在第36行调用了target.onResourceReady()方法。
那么这个target又是什么呢？这个又需要向上翻很久了，在第三步into()方法的一开始，我们就分析了在into()方法的最后一行，调用了glide.buildImageViewTarget()方法来构建出一个Target，而这个Target就是一个GlideDrawableImageViewTarget对象。
那么我们去看GlideDrawableImageViewTarget的源码就可以了，如下所示：
public class GlideDrawableImageViewTarget extends ImageViewTarget<GlideDrawable> {
private static final float SQUARE_RATIO_MARGIN = 0.05f;
private int maxLoopCount;
private GlideDrawable resource;
public GlideDrawableImageViewTarget(ImageView view) {
this(view, GlideDrawable.LOOP_FOREVER);
}
public GlideDrawableImageViewTarget(ImageView view, int maxLoopCount) {
super(view);
this.maxLoopCount = maxLoopCount;
}
@Override
public void onResourceReady(GlideDrawable resource, GlideAnimation<? super GlideDrawable> animation) {
if (!resource.isAnimated()) {
float viewRatio = view.getWidth() / (float) view.getHeight();
float drawableRatio = resource.getIntrinsicWidth() / (float) resource.getIntrinsicHeight();
if (Math.abs(viewRatio - 1f) <= SQUARE_RATIO_MARGIN
&& Math.abs(drawableRatio - 1f) <= SQUARE_RATIO_MARGIN) {
resource = new SquaringDrawable(resource, view.getWidth());
}
}
super.onResourceReady(resource, animation);
this.resource = resource;
resource.setLoopCount(maxLoopCount);
resource.start();
}
@Override
protected void setResource(GlideDrawable resource) {
view.setImageDrawable(resource);
}
@Override
public void onStart() {
if (resource != null) {
resource.start();
}
}
@Override
public void onStop() {
if (resource != null) {
resource.stop();
}
}
}
在GlideDrawableImageViewTarget的onResourceReady()方法中做了一些逻辑处理，包括如果是GIF图片的话，就调用resource.start()方法开始播放图片，但是好像并没有看到哪里有将GlideDrawable显示到ImageView上的逻辑。
确实没有，不过父类里面有，这里在第25行调用了super.onResourceReady()方法，GlideDrawableImageViewTarget的父类是ImageViewTarget，我们来看下它的代码吧：
public abstract class ImageViewTarget<Z> extends ViewTarget<ImageView, Z> implements GlideAnimation.ViewAdapter {
@Override
public void onResourceReady(Z resource, GlideAnimation<? super Z> glideAnimation) {
if (glideAnimation == null || !glideAnimation.animate(resource, this)) {
setResource(resource);
}
}
protected abstract void setResource(Z resource);
}
可以看到，在ImageViewTarget的onResourceReady()方法当中调用了setResource()方法，而ImageViewTarget的setResource()方法是一个抽象方法，具体的实现还是在子类那边实现的。
那子类的setResource()方法是怎么实现的呢？回头再来看一下GlideDrawableImageViewTarget的setResource()方法，没错，调用的view.setImageDrawable()方法，而这个view就是ImageView。代码执行到这里，图片终于也就显示出来了。
那么，我们对Glide执行流程的源码分析，到这里也终于结束了。
总结
- with()方法的作用：通过RequestManagerRetriever的单例静态get方法拿到对象实例，调用成员函数get方法，通过getApplicationManager(Context)方法返回RequestManager实例。
- load()方法的作用：fromString----->loadGeneric------->返回asBitmap相关的DrawableTypeRequest对象----->调用DrawableRequestBuilder父类中load方法------>给父类成员变量赋值-------->最后再RequestManager类中将DrawableRequestBuilder父类对象强转成子类DrawableTypeRequest，也就是说，load方法最终是得到了DrawableTypeRequest对象。
- into()方法的作用：①初始化各种参数，做好准备工作（网络请求、基于MVP的各种接口回调），②使用最原始的HTTPConnect网络连接，读取文件流，③根据文件判断是GIF动图还是Bitmap静态图片，④通过相关复杂逻辑将下载的图片资源取出来，赋值给ImageView控件。
补充，Glide缓存机制：
Glide的缓存分为两种，Resource缓存、Bitmap缓存。
一、Resource缓存：首先Resource缓存就是缓存整体的图片资源文件，缓存它是为了当首次从服务器端下载下来之后，缓存到本地，如果再次使用这个图片，不用去跑网络请求，直接从本地读取，节省流量也提高访问速度。它使用的是三级缓存原理：
一级缓存：内存缓存，缓存被回收的资源，使用LRU算法（Least Frequently Used，最近最少使用算法），当需要再次使用到被回收的资源时，直接从内存中读取；
二级缓存：使用弱引用缓存正在使用的资源，当系统执行GC操作时，会回收没有强引用的资源。使用弱引用缓存，既可以缓存当前正在强引用使用的资源，又不阻碍系统回收无引用的资源
三级缓存：磁盘缓存，网络图片下载成功后，以文件的形式缓存到磁盘中
1和2都是内存缓存，只不过功能不一样，1是使用LRU算法缓存被GC回收的资源，2是用弱引用缓存正在使用的资源。在复用图片资源的时候首先从回收的内存缓存集合中查找，内存缓存的集合中没有的时候，去弱引用集合查找是否是当前正在使用，没有的话，去磁盘中查找，再没有的时候去网络中查找。
二、Bitmap缓存：Bitmap所占的内存大小由其三部分组成：图片宽，高和Bitmap质量参数。
bitmap内存大小 = 宽*高*质量参数所占的位数 ，单位是字节b
- ALPHA—8就是Alpha是由8位组成的（1B）
- ARGB_4444，4个4位组成16位（2B）
- ARGB_8888，4个8位组成32位（4B）
- RGB_565，R是5位，G是6位，B是5位组成16位（2B），Glide默认bitmap压缩参数就是这个RGB_565，但是它不能显示透明度
先说一下为什么要进行bitmap压缩，比如在recycleView中加载大量的图片，频繁的创建和回收Bitmap会导致内存波动影响性能，既然这样，我们能不能缓存Bitmap，不要让它老是new和销毁，这应该是Glide去做Bitmap缓存的原因，
Bitmap缓存算法：在Glide中使用BitmapPool来缓存Bitmap，使用的也是LRU算法（最近最少使用算法），当需要使用Bitmap时，先从Bitmap的池子中选取，如果找不到合适的Bitmap，再去创建，当使用完毕后，不再直接调用Bitmap.recycle()释放内存，而是缓存到Bitmap池子里。
Bitmap的缓存是以键值对的方式进行缓存的，Resource和Bitmap都作为Value，而这些值是需要一个key来标识缓存的内容，根据key可以查找和移除对应的缓存。
参考链接：https://blog.csdn.net/dream_caoyun/article/details/81510582
