版权声明：本博客只做技术交流使用 https://blog.csdn.net/weixin_39452320/article/details/85149886
需要电子档书籍或者源码可以Q群：828202939 希望可以和大家一起学习、一起进步！！
如有错别字或有理解不到位的地方，可以留言或者加微信15250969798，博主会及时修改！！！！！
博主的案例并不难，只是为了更好的给想入门threeJS的同学一点点经验！！！！！
涉及的知识点博主已经从three源码库里面摘要出来放在对应的注释里面！
今天学习three里面json格式模型的加载!这种格式也是官方推荐的格式之一！
效果图：
代码：
<html>
<head>
<title>threeJS19-Loader-json</title>
<style>
body {
background-color: #000;
margin: 0px;
overflow: hidden;
}
#WebGL {
width: 100%;
height: 100%;
position: absolute;
left: 0;
top: 0;
z-index: 999;
}
</style>
</head>
<body>
<script src="http://libs.baidu.com/jquery/2.0.0/jquery.js"></script>
<script src="../../../build/three.js"></script>
<script src="../../js/controls/OrbitControls.js"></script>
<div id="WebGL"></div>
<script>
'use strict';
var container, camera, scene, renderer, geometry, material, animate, controls; //常用变量
var spotLight, mshStdBox; //自定义对象变量
var target = new THREE.Vector3(0, 30, 0);
var model, skeleton;
var webGLW = $('#WebGL').width();
var webGLH = $('#WebGL').height();
var clock = new THREE.Clock();
var mixer; //存放动画数据
init();
animate();
function init() {
container = document.getElementById('WebGL');
scene = new THREE.Scene();
scene.background = new THREE.Color(0xcfcfcf);
scene.fog = new THREE.Fog(0xa0a0a0, 200, 1000); //雾
camera = new THREE.PerspectiveCamera(40, window.innerWidth / window.innerHeight, 0.1, 1000);
camera.position.set(0, 100, -150);
var ambient = new THREE.AmbientLight(0xffffff);
scene.add(ambient);
lights(); //灯光：聚光灯
lightsHelper(spotLight); //灯光显示助手
plane() //// 地面
Box(); //旋转的立方体
loadModel(); //添加人物模型
rendererScene(); //场景渲染
OrbitControls(camera, renderer); //OrbitControls控件模块，90版本鼠标右键上下是移动，96版本之后右键上下是缩放
window.addEventListener('resize', onWindowResize, false); //监听屏幕变化
}
function plane() {
// 地面
let grid_mesh = new THREE.Mesh(new THREE.PlaneBufferGeometry(2000, 2000), new THREE.MeshPhongMaterial({
color: 0x999999,
depthWrite: false
}));
grid_mesh.rotation.x = -Math.PI / 2;
grid_mesh.receiveShadow = true;
scene.add(grid_mesh);
var grid = new THREE.GridHelper(2000, 20, 0x000000, 0x000000);
grid.material.opacity = 0.2;
grid.material.transparent = true;
scene.add(grid);
}
function Box() {
// BoxGeometry( width, height, depth, widthSegments, heightSegments, depthSegments )
geometry = new THREE.BoxGeometry(80, 5, 80, 3, 3, 3);
var matStdObjects = new THREE.MeshStandardMaterial({
color: 0xA0cf00,
roughness: 0,
metalness: 0.6
});
mshStdBox = new THREE.Mesh(geometry, matStdObjects);
mshStdBox.position.set(0, -5, 0);
mshStdBox.rotation.set(0, Math.PI / 2.0, 0);
mshStdBox.castShadow = true;
mshStdBox.receiveShadow = true;
scene.add(mshStdBox);
}
function lights() {
// SpotLight( color：颜色, intensity：强度, distance：发光距离, angle：角度, penumbra：边缘范围, decay：衰减 )
spotLight = new THREE.SpotLight(0xffffff, 1);
spotLight.position.set(10, 120, -30);
spotLight.angle = Math.PI / 4;
spotLight.penumbra = 0.05; //边缘范围，反比
spotLight.decay = 2; //衰减系数，反比
spotLight.distance = 400; //发光距离
spotLight.castShadow = true; //阴影
spotLight.shadow.mapSize.width = 1024;
spotLight.shadow.mapSize.height = 1024;
spotLight.shadow.camera.near = 10; //近截面
spotLight.shadow.camera.far = 250;
scene.add(spotLight);
}
function lightsHelper(lightsObject) {
// 聚光灯显示助手SpotLightHelper( light:灯光, color：颜色 )
var lightHelper = new THREE.SpotLightHelper(lightsObject, 0xdfdfdf);
scene.add(lightHelper);
var mesh = new THREE.Mesh(new THREE.PlaneBufferGeometry(200, 200), new THREE.MeshPhongMaterial({
color: 0x9cfcf99,
depthWrite: false
}));
mesh.rotation.x = -Math.PI / 2;
mesh.position.set(0, -20, 0)
mesh.receiveShadow = true;
scene.add(mesh);
}
function loadModel() { //加载模型
// json
var loader = new THREE.JSONLoader();
loader.load('../../models/json/legacy/monster/monster.js', function (geometry, materials) {
material = materials[0];
material.morphTargets = true;
material.color.setHex(0xffaaaa);
var mesh = new THREE.Mesh(geometry, materials);
mesh.scale.set(0.05, 0.05, 0.05);
mesh.position.set(0,0,50);
mesh.rotation.y = Math.PI /2;
console.log('mesh', mesh);
//动画部分
mixer = new THREE.AnimationMixer(mesh);
var action = mixer.clipAction(geometry.animations[0]);
action.play();
scene.add(mesh);
});
}
function onWindowResize() {
camera.aspect = window.innerWidth / window.innerHeight;
camera.updateProjectionMatrix();
renderer.setSize(window.innerWidth, window.innerHeight);
}
function rendererScene() {
renderer = new THREE.WebGLRenderer({
antialias: true
});
renderer.setPixelRatio(window.devicePixelRatio);
renderer.setSize(window.innerWidth, window.innerHeight);
renderer.shadowMap.enabled = true;
renderer.shadowMap.type = THREE.PCFSoftShadowMap;
renderer.gammaInput = true;
renderer.gammaOutput = true;
container.appendChild(renderer.domElement);
}
function OrbitControls(camera, renderer) {
//OrbitControls控件操作模块
controls = new THREE.OrbitControls(camera, renderer.domElement);
controls.target = target; //控制的target
controls.autoRotate = true; //是否自动旋转
controls.autoRotateSpeed = 0.5; //自动旋转速度，正比
}
function animate() {
requestAnimationFrame(animate);
if (controls) controls.update();
mshStdBox.rotation.y += 0.01;
var delta = clock.getDelta();
if (mixer) mixer.update(delta);
renderer.render(scene, camera);
};
</script>
</body>
</html>
