深度学习编器CINN(2)：以reciprocal算子为例看算子开发方法

std::vector<Type> InferDtypeForReciprocal(const std::vector<Type> &inputs_type, const framework::AttrMapType &attrs) {
  CHECK(!inputs_type.empty()) << "The input's type size is 0! Please check again.";
  std::vector<Type> res{inputs_type[0]};
  return res;
}

InferShapeForReciprocal

获取结果张量的shape。

std::vector<framework::shape_t> InferShapeForReciprocal(const std::vector<framework::shape_t> &inputs_shape,
                                                        const framework::AttrMapType &attrs) {
  CHECK(!inputs_shape.empty() && !inputs_shape[0].empty()) << "The input's shape size is 0! Please check again.";
  std::vector<framework::shape_t> res{inputs_shape[0]};
  return res;
}

Reciprocal

实现取倒数的功能。其实我没有看懂extern_func这个操作，应该是写的有冗余啊。extern_func是在lang::CallExtern()需要被用到的，参考logical_right_shift中的操作：CINN/logical_right_shift.cc at 387422e99f6bb897ed1343cd72409d1376a16676 · PaddlePaddle/CINN · GitHub

作者可能是直接抄了，但是没有用到吧。

ir::Tensor Reciprocal(const ir::Tensor &input, const std::string &output_name) {
  std::string extern_func = "cinn_";

  extern_func += "reciprocal";

  if (input->type().is_float(32)) {
    extern_func += "_fp32";
  } else if (input->type().is_float(64)) {
    extern_func += "_fp64";
  } else if (input->type().is_float(16)) {
    extern_func += "_fp16";
  } else {
    CINN_NOT_IMPLEMENTED
  }

  return {Compute(
      input->shape,
      [=](const std::vector<Expr> &indice) {
        ir::Tensor out_tensor(input);
        auto e = out_tensor(indice);
        return common::make_const(input->type(), 1.0f) / e;
      },
      output_name)};
}

StrategyForReciprocal

注册计算compute和优化schedule。前面只是实现了取倒数的IR，这里需要说明清楚如果来了真实数据之后如何处理。

最重要的用compute和schedule构造返回的strategy：

  auto strategy = std::make_shared<framework::OpStrategy>();
  strategy->AddImpl(
      reciprocal_compute, framework::GetInjectiveScheduleFunc(output_shapes, target), "strategy.reciprocal.x86", 1);
  return strategy;

compute是调用上面Reciprocal实现的，添加真实数据的处理功能，依赖CINNValue和CINNValuePack实现。首先构造输入的数据：

    CINNValuePack pack_args = args[0];
    CHECK(!pack_args.empty()) << "at least one input tensor for " << op_name << " compute\n";
    std::string tensor_name = UniqName("Reciprocal_out");

    if (FLAGS_cinn_ir_schedule) {
      CHECK_EQ(pack_args.size(), 2);
      CHECK(pack_args[1].is_string());
      tensor_name = pack_args[1].operator std::string();
    }
    Expr A = pack_args[0];
    CHECK(A.as_tensor());
    CHECK(!output_shapes.empty());
    auto tensor_A = A.as_tensor_ref();
    auto stages   = CreateStages({tensor_A});
    VLOG(3) << "A shape: " << utils::Join(tensor_A->shape, ", ")
            << ", output_shapes: " << utils::Join(output_shapes[0], ", ");

    if (FLAGS_cinn_ir_schedule) {
      CHECK_EQ(pack_args.size(), 2U);
      tensor_name = pack_args[1].operator std::string();
    }

然后调用刚刚写好的Reciprocal函数：

    ir::Tensor out = Reciprocal(tensor_A, tensor_name);
    std::vector<CINNValue> res;
    stages->InsertLazily(out);

然后用得到的结果创造schedule，优化的事情交给更底层的实现：

framework::GetInjectiveScheduleFunc(output_shapes, target),

最后具体看看完整的strategy是如何实现的：

framework::CINNCompute reciprocal_compute([=](lang::Args args, lang::RetValue *ret) {
    CHECK(!args.empty()) << "The input argument of " << op_name << " compute is empty! Please check.\n";
    CINNValuePack pack_args = args[0];
    CHECK(!pack_args.empty()) << "at least one input tensor for " << op_name << " compute\n";

    std::string tensor_name = UniqName("Reciprocal_out");

    if (FLAGS_cinn_ir_schedule) {
      CHECK_EQ(pack_args.size(), 2);
      CHECK(pack_args[1].is_string());
      tensor_name = pack_args[1].operator std::string();
    }

    Expr A = pack_args[0];
    CHECK(A.as_tensor());
    CHECK(!output_shapes.empty());
    auto tensor_A = A.as_tensor_ref();
    auto stages   = CreateStages({tensor_A});
    VLOG(3) << "A shape: " << utils::Join(tensor_A->shape, ", ")
            << ", output_shapes: " << utils::Join(output_shapes[0], ", ");

    if (FLAGS_cinn_ir_schedule) {
      CHECK_EQ(pack_args.size(), 2U);
      tensor_name = pack_args[1].operator std::string();
    }

    ir::Tensor out = Reciprocal(tensor_A, tensor_name);
    std::vector<CINNValue> res;
    stages->InsertLazily(out);
    res.push_back(CINNValue(out));
    CHECK(!out_type.empty()) << "Output type of Reciprocal is empty! Please check.\n";
    res.push_back(CINNValue(stages));
    *ret = CINNValuePack{res};
  });

单元测试

需要先熟悉一下unittest详解_tlqwanttolearnit的博客-CSDN博客

setUpClass：整个测试开始后执行，只执行一次
tearDownClass：整个测试完成后执行，只执行一次
setUp：每运行一次用例前都会执行一次
tearDown：每运行一次用例后都会执行一次

测试用例的命名规则为test_xxx，不以test_xxx命名的函数是方法，方法是不能被执行的。

CINN中按照下面这个模板搭建class

@OpTestTool.skip_if(not is_compiled_with_cuda(),
                    "x86 test will be skipped due to timeout.")
class TestNormOp(OpTest):
    def setUp(self):
        self.init_case()

    def init_case(self):

    def build_paddle_program(self, target):


    def build_cinn_program(self, target):


    def test_check_results(self):
        self.check_results()

if __name__ == "__main__":
    unittest.main()

在setUp()方法中初始化inputs：

    def setUp(self):
        self.init_case()

    def init_case(self):
        self.inputs = {"x": np.random.random([32]).astype("float32")}

build_paddle_program()是调用了paddle.reciprocal方法得到结果，build_cinn_program()调用了我们自己实现的OP得到结果，最后check一下，大功告成！

完整代码如下：

# Copyright (c) 2022 CINN Authors. All Rights Reserved.
#
# Licensed under the Apache License, Version 2.0 (the "License");
# you may not use this file except in compliance with the License.
# You may obtain a copy of the License at
#
#     http://www.apache.org/licenses/LICENSE-2.0
#
# Unless required by applicable law or agreed to in writing, software
# distributed under the License is distributed on an "AS IS" BASIS,
# WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
# See the License for the specific language governing permissions and
# limitations under the License.

import cinn
import numpy as np
import paddle
import unittest

from cinn.frontend import *
from cinn.common import *
from op_test import OpTest, OpTestTool


class TestReciprocalOp(OpTest):
    def setUp(self):
        self.init_case()

    def init_case(self):
        self.inputs = {"x": np.random.random([32]).astype("float32")}

    def build_paddle_program(self, target):
        x = paddle.to_tensor(self.inputs["x"], stop_gradient=True)
        out = paddle.reciprocal(x)
        self.paddle_outputs = [out]

    def build_cinn_program(self, target):
        builder = NetBuilder("reciprocal_test")
        x = builder.create_input(Float(32), self.inputs["x"].shape, "x")
        out = builder.reciprocal(x)

        prog = builder.build()
        res = self.get_cinn_output(prog, target, [x], [self.inputs["x"]],
                                   [out])
        self.cinn_outputs = [res[0]]

    def test_check_results(self):
        self.check_outputs_and_grads()


class TestReciprocalCase1(TestReciprocalOp):
    def init_case(self):
        self.inputs = {"x": np.random.random([32]).astype("float32")}


class TestReciprocalCase2(TestReciprocalOp):
    def init_case(self):
        self.inputs = {"x": np.random.random([10]).astype("float32")}


class TestReciprocalCase3(TestReciprocalOp):
    def init_case(self):
        self.inputs = {"x": np.random.random([1, 10]).astype("float32")}


if __name__ == "__main__":
    unittest.main()

写在最后

熟悉了算子开发的流程，下一篇博客我们自己开始写简单的算子练练手吧！
