VTK 体绘 MIP

开发工具 vs2017 qt 5.2.1 VTK 7.1.1

 #include "vtkDICOMImageReader.h"
#include "vtkPiecewiseFunction.h"
#include "vtkColorTransferFunction.h"
#include "vtkVolumeProperty.h"
#include "vtkVolumeRayCastCompositeFunction.h"
#include "vtkVolumeRayCastMapper.h"
#include "vtkVolume.h"
#include "vtkRenderer.h"
#include "vtkRenderWindow.h"
#include "vtkRenderWindowInteractor.h"
#include "vtkImageCast.h"
#include "vtkImageShiftScale.h"
#include "vtkImageShrink3D.h"
#include "vtkImageThreshold.h"
#include "vtkImageIslandRemoval2D.h"
#include "vtkImageMathematics.h"
#include "vtkImageShrink3D.h"
#include <vtk.h>
void main()
{
	vtkRenderer *ren = vtkRenderer::New();
	vtkRenderWindow *renWin = vtkRenderWindow::New();
	renWin->AddRenderer(ren);

	vtkRenderWindowInteractor *iren = vtkRenderWindowInteractor::New();
	iren->SetRenderWindow(renWin);

	vtkDICOMImageReader   *reader = vtkDICOMImageReader::New();
	reader->SetDataByteOrderToLittleEndian();
	reader->SetDirectoryName("E://CT");
	reader->SetDataOrigin(0.0, 0.0, 0.0);

	vtkImageShrink3D *shrink = vtkImageShrink3D::New();
	shrink->SetInputData((vtkDataObject *)reader->GetOutput());
	shrink->SetShrinkFactors(2, 2, 1);//你要缩得更小

	vtkImageShiftScale *ShiftScale1 = vtkImageShiftScale::New();
	ShiftScale1->SetInputData((vtkDataObject *)shrink->GetOutput());
	ShiftScale1->SetOutputScalarTypeToShort();
	ShiftScale1->SetShift(1024);
	ShiftScale1->ClampOverflowOn();

	vtkImageCast *readerImageCast1 = vtkImageCast::New();
	readerImageCast1->SetInputData((vtkDataObject *)ShiftScale1->GetOutput());
	readerImageCast1->SetOutputScalarTypeToUnsignedShort();
	readerImageCast1->ClampOverflowOn();
	//////////////////////

	vtkImageThreshold  *threshold1 = vtkImageThreshold::New();
	threshold1->SetInputConnection(shrink->GetOutputPort());
	threshold1->ThresholdBetween(-500, 200);
	threshold1->SetInValue(1);
	threshold1->SetOutValue(0);
	threshold1->ReplaceOutOn();
	threshold1->Update();

	vtkImageIslandRemoval2D *island = vtkImageIslandRemoval2D::New();
	island->SetInputConnection(threshold1->GetOutputPort());
	island->SetIslandValue(1);
	island->SetReplaceValue(0);
	island->SetAreaThreshold(7500);
	island->SquareNeighborhoodOn();

	vtkImageShiftScale *ShiftScale = vtkImageShiftScale::New();
	ShiftScale->SetInputData((vtkDataObject *)island->GetOutput());
	ShiftScale->SetOutputScalarTypeToUnsignedShort();
	ShiftScale->ClampOverflowOn();

	////////////////////////
	vtkImageMathematics *mathematic = vtkImageMathematics::New();
	mathematic->SetInputData((vtkDataObject *)readerImageCast1->GetOutput());
	mathematic->SetInputData((vtkDataObject *)ShiftScale->GetOutput());
	mathematic->SetOperationToMultiply();

	reader->Delete();

	vtkPiecewiseFunction *opacityTransferFunction = vtkPiecewiseFunction::New();
	opacityTransferFunction->AddPoint(490, 0.0);
	opacityTransferFunction->AddPoint(500, 0.0);
	opacityTransferFunction->AddPoint(900, 0.0);
	opacityTransferFunction->AddPoint(1024 - 100, 0.07);
	opacityTransferFunction->AddPoint(1024, 0.01);
	opacityTransferFunction->AddPoint(1024 + 100, 0.06);
	opacityTransferFunction->AddPoint(1024 + 160, 0.3);
	opacityTransferFunction->AddPoint(1024 + 200, 0.5);
	opacityTransferFunction->ClampingOff();

	vtkColorTransferFunction *colorTransferFunction = vtkColorTransferFunction::New();
	colorTransferFunction->AddRGBPoint(500.0, 1.0, 0.5, 0.2);
	colorTransferFunction->AddRGBPoint(900.0, 0.80, 0.5, 0.3);
	colorTransferFunction->AddRGBPoint(1000.0, 1.0, 0.9, 0.5);

	colorTransferFunction->AddRGBPoint(1024 + 0.0, 0.0, 0.5, 0.0);
	colorTransferFunction->AddRGBPoint(1024 + 60.0, 1.0, 0.0, 0.0);
	//	colorTransferFunction->AddRGBPoint(1024+60.0, 0.6, 0.1, 0.1);
	colorTransferFunction->AddRGBPoint(1024 + 128.0, 0.2, 0.1, 0.9);
	colorTransferFunction->AddRGBPoint(1024 + 196.0, 0.27, 0.21, 0.1);
	colorTransferFunction->AddRGBPoint(1024 + 255.0, 0.8, 0.8, 0.8);

	vtkVolumeProperty *volumeProperty = vtkVolumeProperty::New();
	//设定一个体绘容器的属性
	volumeProperty->SetColor(colorTransferFunction);
	volumeProperty->SetScalarOpacity(opacityTransferFunction);
	volumeProperty->ShadeOn();
	volumeProperty->SetInterpolationTypeToLinear();

	volumeProperty->SetAmbient(0.2);
	volumeProperty->SetDiffuse(0.9);
	volumeProperty->SetSpecular(0.2);
	volumeProperty->SetSpecularPower(10);
	/**/

	vtkVolumeRayCastCompositeFunction *compositeFunction = vtkVolumeRayCastCompositeFunction::New();
	//运行沿着光线合成

	vtkVolumeRayCastMapper *volumeMapper = vtkVolumeRayCastMapper::New();
	//体绘制器,特点:slow but accurate
	volumeMapper->SetVolumeRayCastFunction(compositeFunction); //体绘光线投射函数
	volumeMapper->SetInputConnection(mathematic->GetOutputPort());//图像数据输入

	vtkVolume *volume = vtkVolume::New();
	//表示透示图中的一组三维数据
	volume->SetMapper(volumeMapper);
	volume->SetProperty(volumeProperty);

	ren->AddVolume(volume);
	ren->SetBackground(1, 1, 1);
	renWin->SetSize(600, 600);
	renWin->Render();

	//    iren-> SetStillUpdateRate(0.5);
	iren->SetDesiredUpdateRate(99);

	iren->Initialize();
	iren->Start();
	ren->ResetCameraClippingRange();

	volumeMapper->Delete();
	iren->Delete();
	ren->Delete();
	renWin->Delete();
	opacityTransferFunction->Delete();
	volumeProperty->Delete();
	compositeFunction->Delete();
	volume->Delete();
	colorTransferFunction->Delete();

}
